Electrical Parts List
225M 225MU 325M 325MU
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
491 PCB MAIN AS R253 R CARBON FILM RD-AZ222J- 1/6 2.2K OHM J o o o o
492 PCB MAIN AS R254 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
493 PCB MAIN AS R255 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
494 PCB MAIN AS R256 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
495 PCB MAIN AS R257~258 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
496 PCB MAIN AS R259 R CARBON FILM RD-AZ123J- 1/6 12K OHM J o o o o
497 PCB MAIN AS R260~263 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
498 PCB MAIN AS R264~265 R CARBON FILM RD-AZ222J- 1/6 2.2K OHM J o o o o
499 PCB MAIN AS R401~402 R CARBON FILM RD-AZ123J- 1/6 12K OHM J o o
500 PCB MAIN AS R401~402 R CARBON FILM RD-AZ153J- 1/6 15K OHM J o o
501 PCB MAIN AS R403~404 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o o o o
502 PCB MAIN AS R405~406 R CARBON FILM RD-AZ123J- 1/6 12K OHM J o o o o
503 PCB MAIN AS R407~408 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
504 PCB MAIN AS R409~410 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
505 PCB MAIN AS R411~412 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o
506 PCB MAIN AS R411~412 R CARBON FILM RD-AZ153J- 1/6 15K OHM J o
507 PCB MAIN AS R413~414 R CARBON FILM RD-AZ182J- 1/6 1.8K OHM J o o o o
508 PCB MAIN AS R415~416 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o o
509 PCB MAIN AS R421~422 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
510 PCB MAIN AS R423~424 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
511 PCB MAIN AS R425~426 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
512 PCB MAIN AS R427 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
513 PCB MAIN AS R429 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
514 PCB MAIN AS R431~432 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
515 PCB MAIN AS R433~434 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
516 PCB MAIN AS R436~437 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
517 PCB MAIN AS R441 R CARBON FILM RD-AZ820J- 1/6 82 OHM J o o o o
518 PCB MAIN AS R501 R CARBON FILM RD-AZ124J- 1/6 120K OHM J o o o o
519 PCB MAIN AS R502~505 R CARBON FILM RD-AZ393J- 1/6 39K OHM J o o o o
520 PCB MAIN AS R506 R CARBON FILM RD-AZ124J- 1/6 120K OHM J o o o o
521 PCB MAIN AS R507 R CARBON FILM RD-AZ153J- 1/6 15K OHM J o o o o
522 PCB MAIN AS R508~509 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
523 PCB MAIN AS R510 R CARBON FILM RD-AZ220J- 1/6 22 OHM J o o o o
524 PCB MAIN AS R511 R CARBON FILM RD-AZ824J- 1/6 820K OHM J o o o o
525 PCB MAIN AS R512 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
526 PCB MAIN AS R513 R CARBON FILM RD-AZ474J- 1/6 470K OHM J o o o o
527 PCB MAIN AS R514 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
528 PCB MAIN AS R515 R CARBON FILM RD-AZ682J- 1/6 6.8K OHM J o o o o
529 PCB MAIN AS R516 R CARBON FILM RD-AZ153J- 1/6 15K OHM J o o o o
530 PCB MAIN AS R517 R CARBON FILM RD-AZ273J- 1/6 27K OHM J o o o o
531 PCB MAIN AS R518 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
532 PCB MAIN AS R519~520 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
533 PCB MAIN AS R521 R CARBON FILM RD-AZ154J- 1/6 150K OHM J o o o o
534 PCB MAIN AS R522~523 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
535 PCB MAIN AS R524 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
536 PCB MAIN AS R525 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
537 PCB MAIN AS R526 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
538 PCB MAIN AS R527 R CARBON FILM RD-AZ154J- 1/6 150K OHM J o o o
539 PCB MAIN AS R527 R CARBON FILM RD-AZ474J- 1/6 470K OHM J o
540 PCB MAIN AS R528 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
541 PCB MAIN AS R529~530 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
542 PCB MAIN AS R531 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
543 PCB MAIN AS R532 R CARBON FILM RD-AZ683J- 1/6 68K OHM J o o o o
544 PCB MAIN AS R533 R CARBON FILM RD-AZ823J- 1/6 82K OHM J o o o o
545 PCB MAIN AS R534 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
546 PCB MAIN AS R535 R CARBON FILM RD-AZ183J- 1/6 18K OHM J o o o o
547 PCB MAIN AS R536 R CARBON FILM RD-AZ563J- 1/6 56K OHM J o o o o
548 PCB MAIN AS R537 R CARBON FILM RD-AZ273J- 1/6 27K OHM J o o o o
549 PCB MAIN AS R538 R CARBON FILM RD-AZ563J- 1/6 56K OHM J o o o o
550 PCB MAIN AS R539 R CARBON FILM RD-AZ184J- 1/6 180K OHM J o o o o
551 PCB MAIN AS R540 R CARBON FILM RD-AZ153J- 1/6 15K OHM J o o o o
552 PCB MAIN AS R541 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
553 PCB MAIN AS R542 R CARBON FILM RD-AZ683J- 1/6 68K OHM J o o o o
554 PCB MAIN AS R543 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
555 PCB MAIN AS R544 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o o
556 PCB MAIN AS R545~546 R CARBON FILM RD-AZ273J- 1/6 27K OHM J o o o o
557 PCB MAIN AS R547 R CARBON FILM RD-AZ683J- 1/6 68K OHM J o o o o
558 PCB MAIN AS R548 R CARBON FILM RD-AZ333J- 1/6 33K OHM J o o o o
559 PCB MAIN AS R549 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
560 PCB MAIN AS R550 R CARBON FILM RD-AZ333J- 1/6 33K OHM J o o o o
