Electrical Parts List
225M 225MU 325M 325MU
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
561 PCB MAIN AS R551~552 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
562 PCB MAIN AS R553 R CARBON FILM RD-AZ154J- 1/6 150K OHM J o o o o
563 PCB MAIN AS R554 R CARBON FILM RD-AZ105J- 1/6 1M OHM J o o o o
564 PCB MAIN AS R555~556 R CARBON FILM RD-2Y150J- 1/2 15 OHM J o o o o
565 PCB MAIN AS R557 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
566 PCB MAIN AS R558 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
567 PCB MAIN AS R559 R CARBON FILM RD-AZ822J- 1/6 8.2K OHM J o o o o
568 PCB MAIN AS R560 R CARBON FILM RD-AZ123J- 1/6 12K OHM J o o o o
569 PCB MAIN AS R561 R CARBON FILM RD-AZ273J- 1/6 27K OHM J o o o o
570 PCB MAIN AS R562~563 R CARBON FILM RD-AZ332J- 1/6 3.3K OHM J o o o o
571 PCB MAIN AS R564 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
572 PCB MAIN AS R567 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
573 PCB MAIN AS R568 R CARBON FILM RD-AZ221J- 1/6 220 OHM J o o o o
574 PCB MAIN AS R569 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
575 PCB MAIN AS R570 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
576 PCB MAIN AS R571 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
577 PCB MAIN AS R572~573 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
578 PCB MAIN AS R574~579 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
579 PCB MAIN AS R580~581 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
580 PCB MAIN AS R582 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
581 PCB MAIN AS R601~604 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
582 PCB MAIN AS R605~606 R CARBON FILM RD-AZ820J- 1/6 82 OHM J o o o o
583 PCB MAIN AS R607~608 R CARBON FILM RD-AZ683J- 1/6 68K OHM J o o o o
584 PCB MAIN AS R609~610 R CARBON FILM RD-AZ682J- 1/6 6.8K OHM J o o o o
585 PCB MAIN AS R613~614 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
586 PCB MAIN AS R615~616 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o o o o
587 PCB MAIN AS R617~618 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
588 PCB MAIN AS R619 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
589 PCB MAIN AS R620 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o
590 PCB MAIN AS R622 R CARBON FILM RD-AZ105J- 1/6 1M OHM J o o o o
591 PCB MAIN AS R623 R CARBON FILM RD-AZ184J- 1/6 180K OHM J o o o o
592 PCB MAIN AS R624 R CARBON FILM RD-AZ563J- 1/6 56K OHM J o o o o
593 PCB MAIN AS R625~626 R CARBON FILM RD-AZ184J- 1/6 180K OHM J o o o o
594 PCB MAIN AS R627~628 R CARBON FILM RD-AZ151J- 1/6 150 OHM J o o o o
595 PCB MAIN AS R629~630 R CARBON FILM RD-AZ224J- 1/6 220K OHM J o o o o
596 PCB MAIN AS R631~632 R CARBON FILM RD-AZ682J- 1/6 6.8K OHM J o o o o
597 PCB MAIN AS R633~634 R CARBON FILM RD-AZ392J- 1/6 3.9K OHM J o o o o
598 PCB MAIN AS R635~636 R CARBON FILM RD-AZ821J- 1/6 820 OHM J o o o o
599 PCB MAIN AS R637~638 R CARBON FILM RD-AZ184J- 1/6 180K OHM J o o o o
600 PCB MAIN AS R639~642 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
601 PCB MAIN AS R643~644 R CARBON FILM RD-AZ183J- 1/6 18K OHM J o o o o
602 PCB MAIN AS R645~646 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
603 PCB MAIN AS R647 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
604 PCB MAIN AS R648 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o
605 PCB MAIN AS R649 R CARBON FILM RD-AZ683J- 1/6 68K OHM J o o o o
606 PCB MAIN AS R651 R CARBON FILM RD-AZ184J- 1/6 180K OHM J o o o o
607 PCB MAIN AS R652 R CARBON FILM RD-AZ479J- 1/6 4.7 OHM J o o o o
608 PCB MAIN AS R653 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o o
609 PCB MAIN AS R654 R CARBON FILM RD-AZ271J- 1/6 270 OHM J o o o o
610 PCB MAIN AS R655 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
611 PCB MAIN AS R656 R CARBON FILM RD-AZ333J- 1/6 33K OHM J o o o o
612 PCB MAIN AS R657 R CARBON FILM RD-AZ470J- 1/6 47 OHM J o o o o
613 PCB MAIN AS R658 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o o
614 PCB MAIN AS R659 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
615 PCB MAIN AS R662 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
616 PCB MAIN AS R663 R CARBON FILM RD-AZ331J- 1/6 330 OHM J o o o o
617 PCB MAIN AS R664 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
618 PCB MAIN AS R665 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
619 PCB MAIN AS R666 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
620 PCB MAIN AS R667~668 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o
621 PCB MAIN AS R669 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
622 PCB MAIN AS R670~671 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
623 PCB MAIN AS R672 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
624 PCB MAIN AS R674~675 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
625 PCB MAIN AS R676 R CARBON FILM RD-AZ105J- 1/6 1M OHM J o o o o
626 PCB MAIN AS R677 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o
627 PCB MAIN AS R677 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o
628 PCB MAIN AS R678 R CARBON FILM RD-AZ224J- 1/6 220K OHM J o o o o
629 PCB MAIN AS R681 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o
630 PCB MAIN AS R803~804 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
