Electrical Parts List
225M 225MU 325M 325MU
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
631 PCB MAIN AS R805~806 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o o
632 PCB MAIN AS R807~808 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o
633 PCB MAIN AS R807~808 R CARBON FILM RD-AZ681J- 1/6 680 OHM J o o
634 PCB MAIN AS R809 R CARBON FILM RD-4Z479J- 1/4 4.7 OHM J o
635 PCB MAIN AS R810 R CARBON FILM RD-4Z479J- 1/4 4.7 OHM J o o o o
636 PCB MAIN AS R811 R CARBON FILM RD-4Z479J- 1/4 4.7 OHM J o o o
637 PCB MAIN AS R813~814 R CARBON FILM RD-AZ183J- 1/6 18K OHM J o
638 PCB MAIN AS R815~818 R CARBON FILM RD-4Z102J- 1/4 1K OHM J o o o o
639 PCB MAIN AS R821 R CARBON FILM RD-AZ154J- 1/6 150K OHM J o o o o
640 PCB MAIN AS R823~824 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
641 PCB MAIN AS R825 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
642 PCB MAIN AS R827 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o
643 PCB MAIN AS R829 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o
644 PCB MAIN AS R831~832 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
645 PCB MAIN AS R910 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
646 PCB MAIN AS R911 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o o o o
647 PCB MAIN AS R913 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
648 PCB MAIN AS R914~915 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o o o o
649 PCB MAIN AS R916 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
650 PCB MAIN AS RF901~902 R FUSIBLE RF01F4780J 0.47OHM 1W o o
651 PCB MAIN AS RV601 R SEMI FIXED RV1417222- 1/10 2.2K OHM B V6EK-PV1S o o o o
652 PCB MAIN AS TP601~602 PIN WRAPPING 9713550400 1.0X2.5X15 o o o
653 PCB MAIN AS TU001 TUNER PACK 9737613201 KST-F401VA-3 o o o o
654 PCB MAIN AS XC201 C DISCRIMINATOR 5P107MG86C CDA10.7MG86N-C o o o o
655 PCB MAIN AS XC251 X-TAL 5XA7R20000 7.2M o o o o
656 PCB MAIN AS XC501 RESONATOR CERA 5PCSA16R93 CSA16.93MXZ04 o o o o
