Fitting the Flexible Exhaust Hose – this must be fitted before use:
1. Twist the Housing Adaptor
(35) and the Window
Connector (37) clockwise
onto the ends of the
flexible Exhaust Hose (36).
2. Align the fixing pip on the
Housing Adaptor (35) with
the notch in the Exhaust
(4) at back of the air
conditioner. Once aligned,
slide the Housing Adaptor
(35) down into place.
3. Place the Window end of the
flexible Exhaust Hose (36) through
a suitable outlet such as an open
window, door, etc.
The unit must be positioned a minimum of 1 Metre away from any wall or
obstruction on all sides.
• Before use, check the flexible Exhaust Hose (36) is properly fitted as above.
• Ensure the unit is on a solid, level, dry surface.
• Ensure the unit is plugged directly into the mains socket and does not share
sockets with other appliances via a mains adaptor or an extension lead, etc.
