1 WASH MOTOR d.c. 310 V, 125 W 36189L8000 DWD200BL, Class F N
2 DRAIN MOTOR 220 V, 3 W 3919601000 SDPV-1, Class E
3 VALVE INLET 220 V, 5.5 W 3615401000 SV-11CWB, Class E Shi
4 WASH HEATER 220 V, 1400 W 3612804000 1R8A721
220 V, 1400 W 1R0X350
5 FUSE 250 V, 15 A MAIN FUSE, 326 LIT
250 V, 15 A M-PCB, 66TL
6 THERMAL FUSE 220 V, 16 A WASH HEATER entrails (2EA)
7 POWER CORD Assy Korea 3611308101 H05VV-F, 3G, 1.5mm
2
, 3 M
3611308202 H05VV-F, 3G, 1.5mm
2
, 5 M
8 POWER PLUG 250 V, 16 A SEE-72GE
9 EMI FILTER 250 V, 12 A 3611913000 DFC-2712D
10 MICRO SWITCH MS-11D
11 X-CAPACITOR 275 V M-PCB, CMI, CM15, PCX2 335M, 0.1 ὺ
12 VARISTOR 560 V SVC561-14 Sam
13 RELAY 250V, 10 A RY8, GA-1A-12L
250V, 10 A RY5, GI-1A-12DH
250V, 10 A RY8, OMI-SH-112LM
250V, 10 A RY8, SMI-S-112LM
250V, 10 A RY5, SJ-S-112DM
250V, 10 A RY1~4, RY6, Y5-1A-12L
250V, 10 A RY1~4, RY6, PCJ-112D3MH
250V, 10 A RY1~4, RY6, SRB-S-112DM
14 PHOTO COUPLER 5KV PC-17K1 K
15 TRANSFORMER M-PCB, TS14-14 Nam
M-PCB, TS14-14 Wo
16 SENSOR PRESSURE 3614825320 DL-DW12-H, AIR INLET 270 HOOK TYPE
17 THERMISTOR WASH 361AAAAB10 R25=1.704ὶ R80=11.981ὶ
18 HARNESS EARTH 3612794420 D-M301 Daes
19 HARNESS AS 361279C000 Cold & Rinse, Heater Dongy
20 EMI SUB HARNESS 361279A620 TR 29 * 19 * 15 G5B 8 Turn Dongyo
21 SWITCH DOOR LOCK 3619047230 DL-S2 ,BITRON, VE-TYPE
NO PART NAME Rating PART CODE BOM DESCRIPTION
6. Part List and Major Specifications
