36
4) Cleaning and Exchange of Drain Housing
[Disassembly]
1 Push the stopper of housing and turn the motor base counterclockwise to detach the bellows.
2 Examine the inside to remove any impurities.
3 Exchange only the motor if the motor causes poor operation.
[Assembly] Re-assemble the parts in the opposite sequence to disassembly.
STOPPER BASE+MOTORDrain Motor + bellows Assembly
To Next Page
