Operation Section
-77-
Displaying Fault Codes (DFC) From SECM
Memory
To enter code display mode you must turn OFF the
ignition key. Now turn ON the key but do not start the
engine. As soon as you turn the key to the ON position
you must cycle the foot pedal by depressing it to the
floor and then fully releasing the pedal (pedal maneuver).
You must fully cycle the foot pedal three (3) times within
five (5) seconds to enable the display codes feature of
the SECM. Simply turn the key OFF to exit display
mode. The code list will continue to repeat until the key
is turned OFF. An automatic code display feature is
activated if a foot pedal fault condition exists. This
feature enables the service technician to view the fault
codes by turning the key to the ON position, if a foot
pedal malfunction is preventing the retrieval of the
stored fault codes from the SECM.
ON OFF
= CODE 12
Malfunction Indicator Light (MIL)
ON ON OFF
To Next Page
