Maintenance Section
-133-
3. Remove the dip stick/filter cap. Fill the drive axle
housing with oil. See “Lubricant Specification - Drive
Axle Oil” and “Refill Capacity”
4. Start the lift truck. With the engine at low idle, place
the directional control lever to the NEUTRAL.
5. Maintain the oil level between lower mark and upper
mark on the dip stick/filter cap.
6. Install the dip stick/filter cap.
Parking Brake - Test, Adjust
NOTE: Be sure area around the lift truck is clear of
personnel and obstructions.
1. Drive the lift truck with a capacity load, forward up a
15% incline [a slope that increases 1.5 meters in 10
meters (1.5 ft increase in 10 ft)].
2. Halfway up the incline, stop the lift truck with the
service brake.
3. Apply the parking brake and slowly release the
service brake.
4. The parking brake should hold the lift truck. If the lift
truck starts to move, immediately apply the service
brakes. Have the parking brake adjusted.
