- 68 -
¥
Water Pump
Prior to putting the gasket, spread a liquid gasket.
¥
Cylinder Head Gasket
Make sure mark "Top" is up and mark "Front" is
down.
¥
Assembled Cylinder Head
Orderly and repeatedly tighten bolts with engine oil at
the cylinder head, as shown in figure.
¥
Assembly Rocker Arm Shaft
Orderly tighten the rocker arm bolt as shown in figure.
Adjust valve clearance
Refer to section 1.5.9
EJM2146S
EJM2147S
EJM2148S
EJM2149S
1st step 2nd step 3nd step
dodecagon
4.0
kg ¥ m
90
û
60
û
(0~30
û
)
bolt
torque
Torque 3.1
L
0.5 kg¥ m
Spread liquid gasket
Front, TOP
Front
Front
