- 79 -
4.2. Coolant Pump
¥
Disassembly
EJM4003S
<Disassembly order>
1. Pulley 5. Pulley Flange
2. Cover 6. Snap ring
3. Gasket 7. Seal
4. Impeller 8. Impeller shaft
6
5
7
8
4
3 2
1
