- 77 -
EJM3009S
EJM3010S
<Reassembly order>
1. By-pass valve 4. By-pass valve plug
2. By-pass valve spring 5. Element gasket
3. O-ring : plug 6. Element.
¥ Oil cooler element tigthening bolts
Tighten the bolts with the specified torque after
assembling an oil cooler element.
¥
Reassembly
Reassembly is reverse order of disassembly.
Torque 2.6
L
0.5 kg¥ m
6
1
2
3
4
5
