- 82 -
¥ Unit Bearing
With bench press, set up the unit bearing at the pump.
¥ Snap Ring
Assemble the snap ring with a snap ring plier.
¥ Pulley Center
Assemble pulley center with a bench press.
¥ Washer and Seal Unit
Assemble it with a bench press after putting liguid
gasket to the pump body contacting surface.
EJM4011I
EJM4007S
EJM4015S
EJM4016S
EJM4017S
Spreading of multipurposable grease
Outside from sealed surface
Spreading of
liguid gasket
