2.2.6. Cylinder Head Disassembly Steps
¥
Key
Use the valve spring compressor when removing key
EJM2027S
EJM2024S
<Disassembly Steps>
1. Exhaust manifold and gasket 7. Spring seat (upper) or *Valve rotator
2. Intake manifold and gasket 8. Valve spring
3. Coolant outlet pipe 9. Spring seat (lower)
4. Thermostat 10. Valve
5. Thermostat housing and gasket 11. Valve stem oil seal
6. Key
Valve spring compressor
