5.4. Injection Pump
5.4.1. Adjustment of Injection quantity.
Injection quantity shonld be adjusted,
seeing adjustment data of injection pump model as
described below.
5.3.2. Calibration data
<Test conditions>
- 89 -
101605-9630
0000000000(Serial NO)
Pump NO. 101062-8120
NP-PE S6A95C410RS2000
LICENCE BOSCH
EJM5014I
Injection pump 101605-9630
Injection nozzle D.P.I.C. No. 105025-138A
Injection nozzle holder D.P.I.C. No. 105160-465A
Nozzle opening pressure 220 kg/cm
2
Injection pipe demensions INNER DIA. 1.6mmXOUTER DIA. 6 mm - LENGTH 580 mm
Transter pump pressure 1.6 kg/cm
2
Testing diesel fuel ISO 4
Operating temperature 40~50¡C
<Governor Adjustment>
0
B
E
C
A
340
480
415
350
850
970
1175
1115
9.8
9.1
9.4
6.3
6.4
+
_
0.1
0.3
+ _
0.1
+
_
20
14
OR MORE
EJM5015I
