- 67 -
¥
Flywheel
1) Apply engine oil on the flywheel bolt.
2) Orderly tighten the fly wheel bolt.(see figure)
¥
Injection Pump
Tighten the injection pump bolts to a specified torgue
for "C" marks of injection pump gear and idle gear to
be aligned each other.
¥
Crank shaft pulley nut
Tighten a nut with wrench.
EJM2142S
EJM1029S
EJM2130S
EJM2144S
EJM2145S
Bolt Torque 22.3
L
2.2 kg¥ m
Bolt Torque 2.6
L
0.5 kg¥ m
Torque 60.0
L
5.0 kg¥ m
¥
Tappet Chamber Cover
Tighten a bolt with gasket and liquid gasket.
Torque 2.6
L
0.5 kg¥ m
Injection pump
gear
Idle gear
F
B
F
mark
F
C
F
mark
Camshaft
gear
F
A
F
mark
Crankshaft gear
Crank
shaft
gear
Lubricate with enging oil
pulley
wrench
gasket
