- 82 -
¥ Unit Bearing
With bench press, set up the unit bearing at the pump.
¥ Snap Ring
Assemble the snap ring with a snap ring plier.
¥ Pulley Center
Assemble pulley center with a bench press.
¥ Washer and Seal Unit
Assemble it with a bench press after putting liguid
gasket to the pump body contacting surface.
EJM4011I
EJM4007S
EJM4015S
EJM4016S
EJM4017S
Spreading of multipurposable grease
Outside from sealed surface
Spreading of
liguid gasket
To Next Page
