6
3. Unscrew 1screw and open the electronic controller box cover.
4. Unscrew 1screw and disconnect the wire terminals for replace PCBs.
5. Reverse the above procedure to install.
The outer door covers the door to the dishwasher and protects the detergent dispenser.
Removal and Installation
1. Disconnect power.
2. Open the dishwasher door.
3. Remove the 6 screws and the door panel from the door assembly. Do
not remove the 6 screws that hold the control panel cover to the door
assembly.
The dispenser automatically dispenses both the detergent and the rinse agent at the
appropriate times. The dispenser is activated twice during a wash cycle.
Dispenser
Outer Door
To Next Page
