30
7. Service part list (DLT-19W4)
LOC PART CODE
PART NAME PART DESCRIPTION
M201 4852098411
MASK FRONT 19W4 HIPS BK
M201A 4857818506
CLOTH BLACK CLOTH 240X8XT0.5
M201D 2233039604
PAINT WATER BK9604BP CETELON
M201E 48558000A02T
LABEL POP GLOSSY PET
M561 48556192SD02
MARK BRAND DAEWOO 68MM (20”21”)
M591 485594900001
DECO PLATE 19W4 PC T2.0
ZZ210 PTSPPWG105
SPEAKER AS DLT-19W4LMBSCF
P601A 4850704S41
CONNECTOR YH025-04+YRT205+ULW=300
SP01 4858319910
SPEAKER SP-5090F24C
SP01A 4853956801
BRKT SPKR 19/22W4 HIPS BK
SP01B 7178301051
SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
SP01C 4857818705
CLOTH BLACK FELT T0.7 L=110 W=15
SP01D 4857818705
CLOTH BLACK FELT T0.7 L=110 W=15
SP02 4858319910
SPEAKER SP-5090F24C
SP02A 4853956801
BRKT SPKR 19/22W4 HIPS BK
SP02B 7178301051
SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
SP02C 4857818705
CLOTH BLACK FELT T0.7 L=110 W=15
SP02D 4857818705
CLOTH BLACK FELT T0.7 L=110 W=15
ZZ280 PTCTMSG105
PCB CTRL
MANUAL AS
DLT-19W4LMBSCF
M231 4852335301
PANEL CTRL 19/22W4 HIPS BK
M481 4854873411
BUTTON POWER 19/22W4 ABS
GY340A+SV2405BP
M491 4854965611
BUTTON CH 19/22W4 ABS
GY340A+SV2405BP
M491A 7178301051
SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
P903A 4850703S70
CONNECTOR YH025-03+YBH250-
03+ULW=400
SW17 5S40101009
SW PUSH PS-22E06
ZZ200 PTCTJRG105
PCB CTRL RADIAL
AS
DLT-19W4LMBSCF
SW11 5S50101Z90
SW TACT SKHV10910A
SW12 5S50101Z90
SW TACT SKHV10910A
SW13 5S50101Z90
SW TACT SKHV10910A
SW14 5S50101Z90
SW TACT SKHV10910A
SW15 5S50101Z90
SW TACT SKHV10910A
SW16 5S50101Z90
SW TACT SKHV10910A
ZZ200 PTCTJAG105
PCB CTRL AXIAL
AS
DLT-19W4LMBSCF
A002 4859833714
PCB CONTROL SL-150T 115X23(246X330/
2X8)D1B
R526 RD-AZ102J-
R CARBON FILM 1/6 1K OHM J
R527 RD-AZ122J-
R CARBON FILM 1/6 1.2K OHM J
R528 RD-AZ202J-
R CARBON FILM 1/6 2K OHM J
R529 RD-AZ332J-
R CARBON FILM 1/6 3.3K OHM J
R530 RD-AZ822J-
R CARBON FILM 1/6 8.2K OHM J
ZZ290 PTMPMSG108
PCB MAIN
MANUAL AS
DLT-19W4SMBSCF
10 2193110032
SOLDER WIRE SP001 PHI 3.0MM (LFCO-W3.0)
20 2193011612
SOLDER WIRE LFC-107 (1.6MM)
30 2291050620
FLUX SOLDER DF-2810U (0.810)
40 2291050314
FLUX SOLVENT IM-1000
C634 CEXF1E471V
C ELECTRO 25V RSS 470MF (10X16) TP
LOC PART CODE
PART NAME PART DESCRIPTION
ZZ110 PTACPWG105
ACCESSORY AS DLT-19W4LMBSCF
10 4850Q00910
BATTERY AAA R03 SUPERGARD/ROCKET
20 7178301251
SCREW TAPPTITE TT2 WAS 3X12 MFZN 3CR
M382A 7172401452
SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M382B DMP2505200
BAG P.E. P.E 40X60 DLT-19/22W4
M821 4858213801
BAG INSTRUC-
TION
L. D. P. E. T0. 05X250X400
ZZ100 48B5655H1101
TRANSMITTER
REMOCON
R-55H11 (AAA)
ZZ120 PTBCSHG105
COVER BACK AS DLT-19W4LMBSCF
M211 4852181401
COVER BACK 19W4 HIPS BK
M211A 4857823900
CLOTH BLACK FELT 240X12XT1.0
M211B 4857823900
CLOTH BLACK FELT 240X12XT1.0
M321 4853298800
BRKT VESA 19/22W4 SECC T=1.0
ZZ130 PTPKCPG105B
PACKING AS
PACKING
DLT-19W4SMB-CF
M191 485819E500
PAD 19W4 EPS
M212 485218151101
COVER STAND
BASE
19/22W4 HIPS BK9604BP
M212A 4852716201
LEG BOTTOM CR (14V5)
M382 485383321101
FRAME STAND 19/22W4 HIPS BK9604
M801 DMP5030700
BOX DLT-19W4TB
M822 DMP2504300
BAG P.E. PE FOAM T0.5X700X650
ZZ140 PTCACAG108B
CABINET AS AS-
SEMBLY
DLT-19W4SMB-CF
M191 4851959800
HINGE AS 19/22W4
M191A 7172401452
SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M211B 2TF01612CL
TAPE FILAMENT 12MMX55ME CLEAR
M351 4853535500
HOLDER AC
CORD
14A5 NYLON66 UL/CSA
M361 4853636301
TERMINAL JACK 19/22W4 HIPS BK
M362 485363530101
TERMINAL COVER HIPS BK
M362A 7178301052
SCREW TAPPTITE TT2 WAS 3X10 MFZN BK 3CR
M381C 4956800200
CLAMP WIRE WS-A-2-19
M381D 7172401252
SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
M381E 7008300651
SCREW MACHINE WAS 3X6 MFZN 3CR
M381F 4856815910
CLAMP WIRE EGI T0.4+TUBE+PIE 4.2
P502A 4859000260
CABLE LVDS FMW1214A-31+FH10001-
30+UL1571#30=250MM
PWC1 48599DL002
CORD POWER W/F 6-LO (LOMAX) YH396-43V
V901 485LD16191
LCD PANEL LTM190M2-L31
ZZ200 PTFMSJG105B
MASK FRONT AS DLT-19W4SMB-CF
