73
SVC Key Function Name Description
S1 Heat-Run Mode only block remocon key code input
S2 ADC Adjust Adjust ADC at each input mode.( Appstest 11 )
S3 VOLUME TEST
MIN. MAX. CENTER OFF
S4 EDID Write
According to option it will write to one or two
EEPROM
S5 TEST PATTERN
Black White Off
S6 IC UPGRADE
Press one time (H2) : port #32,33= L,H
Press second time (ST) : port #32,33= L,L
Press third time (OFF) : port #32,33= H,L
S7 Dempol CH Setting Dempol Channel Map Write End ( Appstest 1 )
S8
CUT OFF R
in the future
CUT OFF G
CUT OFF B
DRIVE R
DRIVE G
DRIVE B
S9 LKB Testing Local key board testing
S10 model Option
Set SL150 Model NAME (UK, W/EU, E/EU)
(VOL+ / Vol-)
DLT-19W4SMBS, 22W4SMBS, 20J3AMD
S11 DVB-T RESET
when you upgrade ST5105 by ST Tools
if you press S11 it will reset EEPROM
S12 Factory Reset shipping Mode
13. SVC keys function
