Daewoo DLT-19W4 - Different Part List for Models

39
Model: DLT-19W4 DLT-22W4
LOC PART CODE PART NAME (PART DESCRIPTION) PART CODE PART NAME (PART DESCRIPTION)
M382A 7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK 3CR) 7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK 3CR)
M382B DMP2505200 BAG P.E. (P.E 40X60 DLT-19/22W4) DMP2505200 BAG P.E. (P.E 40X60 DLT-19/22W4)
M388A
M481 4854873411 BUTTON POWER (19/22W4 ABS GY340A+SV2405BP) 4854873411 BUTTON POWER (19/22W4 ABS GY340A+SV2405BP)
M491 4854965611 BUTTON CH (19/22W4 ABS GY340A+SV2405BP) 4854965611 BUTTON CH (19/22W4 ABS GY340A+SV2405BP)
M491A
M542
M551
M551A
M561 48556192SD02 MARK BRAND (DAEWOO 68MM (20”21”)) 48556192SD02 MARK BRAND (DAEWOO 68MM (20”21”))
M591 485594900001 DECO PLATE (19W4 PC T2.0) 485594910001 DECO PLATE (22W4 PC T2.0)
M801 DMP5030700 BOX (DLT-19W4TB) DMP5030900 BOX (DLT-22W4)
P502A 4859000260 CABLE LVDS (FMW1214A-31+FH10001-
30+UL1571#30=250MM)
4859000260 CABLE LVDS (FMW1214A-31+FH10001-
30+UL1571#30=250MM)
P506A 4850705S32 CONNECTOR (YH025-05+YBH250-05+ULW=350) 4850705S32 CONNECTOR (YH025-05+YBH250-05+ULW=350)
P901A
P902A 4850715N09 CONNECTOR (YH025-15+YBNH250-15+ULW=100) 4850715N09 CONNECTOR (YH025-15+YBNH250-15+ULW=100)
QD12
QD12 T2SA1037KB TR CHIP (2SA1037KB) T2SA1037KB TR CHIP (2SA1037KB)
R450
R530 RD-AZ822J- R CARBON FILM (1/6 8.2K OHM J) RD-AZ822J- R CARBON FILM (1/6 8.2K OHM J)
R899
RD56
RD56 HRFT473JBA R CHIP (1/10 47K OHM J 1608) HRFT473JBA R CHIP (1/10 47K OHM J 1608)
SP01 4858319910 SPEAKER (SP-5090F24C) 4858320010 SPEAKER (SP-5090N03C)
SP01A 4853956801 BRKT SPKR (19/22W4 HIPS BK) 4853956801 BRKT SPKR (19/22W4 HIPS BK)
SP01B 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR) 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR)
SP01C 4857818705 CLOTH BLACK (FELT T0.7 L=110 W=15) 4857817300 CLOTH BLACK (CLOTH 152X15XT0.5)
SP01D 4857818705 CLOTH BLACK (FELT T0.7 L=110 W=15) 4857817300 CLOTH BLACK (CLOTH 152X15XT0.5)
SP02 4858319910 SPEAKER (SP-5090F24C) 4858320010 SPEAKER (SP-5090N03C)
SP02A 4853956801 BRKT SPKR (19/22W4 HIPS BK) 4853956801 BRKT SPKR (19/22W4 HIPS BK)
SP02B 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR) 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR)
SP02C 4857818705 CLOTH BLACK (FELT T0.7 L=110 W=15) 4857817300 CLOTH BLACK (CLOTH 152X15XT0.5)
SP02D 4857818705 CLOTH BLACK (FELT T0.7 L=110 W=15) 4857817300 CLOTH BLACK (CLOTH 152X15XT0.5)
SW16 5S50101Z90 SW TACT (SKHV10910A) 5S50101Z90 SW TACT (SKHV10910A)
V901 485LD16191 LCD PANEL (LTM190M2-L31) 485LD16221 LCD PANEL (LTM220M1-L01)
V902 485AS003PL POWER LIPS (IPB-6012M01) 485AS003PL POWER LIPS (IPB-6012M01)
ZZ200 PTMPJ2G105 PCB CHIP MOUNT B AS (DLT-19W4LMBSCF) PTMPJ2G105 PCB CHIP MOUNT B AS (DLT-19W4LMBSCF)
ZZ210 PTSPPWG105 SPEAKER AS (DLT-19W4LMBSCF) PTSPPWG106 SPEAKER AS (DLT-22W4SMBSCF)
ZZ220
ZZ280 PTCTMSG105 PCB CTRL MANUAL AS (DLT-19W4LMBSCF) PTCTMSG105 PCB CTRL MANUAL AS (DLT-19W4LMBSCF)
ZZ290 PTMPMSG108 PCB MAIN MANUAL AS (DLT-19W4SMBSCF) PTMPMSG106 PCB MAIN MANUAL AS (DLT-22W4SMBSCF)
Different part list for models
