Daewoo DLT-19W4 - Page 39

38
Model: DLT-19W4 DLT-22W4
LOC PART CODE PART NAME (PART DESCRIPTION) PART CODE PART NAME (PART DESCRIPTION)
20 7178301251 SCREW TAPPTITE (TT2 WAS 3X12 MFZN 3CR) 7178301251 SCREW TAPPTITE (TT2 WAS 3X12 MFZN 3CR)
A001 4859818992 PCB MAIN (SL-150T 234X189 K4V (WIDE)) 4859818992 PCB MAIN (SL-150T 234X189 K4V (WIDE))
A002 4859833714 PCB CONTROL (SL-150T 115X23(246X330/2X8)D1B) 4859833714 PCB CONTROL (SL-150T 115X23(246X330/2X8)D1B)
C560
CD30
CD30 HCBK102KBA C CHIP CERA (50V X7R 1000PF K 1608) HCBK102KBA C CHIP CERA (50V X7R 1000PF K 1608)
CP1 HCELF220MD C CHIP ELECTRO (16V 22MF CM 4052) HCELF220MD C CHIP ELECTRO (16V 22MF CM 4052)
IC12 1R24FH1B-- IC PREAMP (R24FH1B) 1R24FH1B-- IC PREAMP (R24FH1B)
IC13
J001
J002
J003
JP502 4859293820 CONN WAFER (GT121-31P-TD-A 31P ST) 4859293820 CONN WAFER (GT121-31P-TD-A 31P ST)
LED1 DSPR39MVW- LED (SPR-39MVW (DUAL)) DSPR39MVW- LED (SPR-39MVW (DUAL))
LED2
M191 485819E500 PAD (19W4 EPS) 485819E600 PAD (22W4 EPS)
M191A 7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK 3CR) 7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK 3CR)
M1F1A
M201 4852098411 MASK FRONT (19W4 HIPS BK) 4852098511 MASK FRONT (22W4 HIPS BK)
M201A
M201C 2233032405 PAINT WATER (SV 2405BP CETELON)
M201D 2233039604 PAINT WATER (BK9604BP CETELON) 2233039604 PAINT WATER (BK9604BP CETELON)
M211 4852181401 COVER BACK (19W4 HIPS BK) 4852181601 COVER BACK (22W4 HIPS BK)
M211A
M212 485218151101 COVER STAND BASE (19/22W4 HIPS BK9604BP) 4852181511 COVER STAND BASE (19/22W4 HIPS
GY340A+SV2405BP)
M212A 4852716201 LEG BOTTOM (CR (14V5)) 4852716201 LEG BOTTOM (CR (14V5))
M213
M213A
M213B
M231 4852335301 PANEL CTRL (19/22W4 HIPS BK) 4852335301 PANEL CTRL (19/22W4 HIPS BK)
M381 4853833301 FRAME MAIN PCB (19W4 SECC T0.8 (SEC)) 4853833401 FRAME MAIN PCB (22W4 SECC T0.8 (SEC))
M381A 7178300852 SCREW TAPTITE (TT2 WAS 3X8 MFZN BK 3CR) 7178300852 SCREW TAPTITE (TT2 WAS 3X8 MFZN BK 3CR)
M381B 7178300852 SCREW TAPTITE (TT2 WAS 3X8 MFZN BK 3CR) 7178300852 SCREW TAPTITE (TT2 WAS 3X8 MFZN BK 3CR)
M381C 4852937500 RUBBER BOTTOM (CR60 BK PHI 18.0XT3.0)
M381D 7172401252 SCREW TAPPTITE (TT2 TRS 4X12 MFZN BK 3CR) 7172401252 SCREW TAPPTITE (TT2 TRS 4X12 MFZN BK 3CR)
M381E 7008300651 SCREW MACHINE (WAS 3X6 MFZN 3CR) 7008300651 SCREW MACHINE (WAS 3X6 MFZN 3CR)
M381F 4856815910 CLAMP WIRE (EGI T0.4+TUBE+PIE 4.2) 4856815910 CLAMP WIRE (EGI T0.4+TUBE+PIE 4.2)
M382 485383321101 FRAME STAND (19/22W4 HIPS BK9604) 4853833211 FRAME STAND (19/22W4 HIPS GY340A+SV2405BP)
8. Different part list for models
