40
Model: DLT-20J1 DLT-20J3
LOC PART CODE PART NAME (PART DESCRIPTION) PART CODE PART NAME (PART DESCRIPTION)
20
A001 4859817493 PCB MAIN (SL-150T 234X189 K4V) 4859817493 PCB MAIN (SL-150T 234X189 K4V)
A002 4859833814 PCB CONTROL (SL-150T 140 X34(246X330/
2X5)D1B)
4859833814 PCB CONTROL (SL-150T 140 X34(246X330/2X5)D1B)
C560 HCELF220MD C CHIP ELECTRO (16V 22MF CM 4052) HCELF220MD C CHIP ELECTRO (16V 22MF CM 4052)
CD30 HCBK102KBA C CHIP CERA (50V X7R 1000PF K 1608) HCBK102KBA C CHIP CERA (50V X7R 1000PF K 1608)
CD30
CP1
IC12 1R24FH1B-- IC PREAMP (R24FH1B)
IC13 1R24FH1B-- IC PREAMP (R24FH1B)
J001 85801050GY WIRE COPPER (1/0.5 TIN COATING)
J002 85801050GY WIRE COPPER (1/0.5 TIN COATING)
J003 85801050GY WIRE COPPER (1/0.5 TIN COATING)
JP502 4859297320 CONN WAFER (05002HR-50A01(G)) 4859297320 CONN WAFER (05002HR-50A01(G))
LED1 DSPR39MVW- LED (SPR-39MVW (DUAL))
LED2 DSPR39MVW- LED (SPR-39MVW (DUAL))
M191 485819CM00 PAD (EPS 20J1) 485819D600 PAD (EPS 20J3)
M191A
M1F1A 7172401652 SCREW TAPPTITE (TT2 TRS 4X16 MFZN BK
3CR)
7172401652 SCREW TAPPTITE (TT2 TRS 4X16 MFZN BK 3CR)
M201 4852093421 MASK FRONT (DLT-20J1 HIPS BK) 4852094731B MASK FRONT (DLT-20J3 HIPS BK)
M201A 7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK
3CR)
7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR)
M201C 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN
3CR)
7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR)
M201D 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN
3CR)
7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR)
M211 4852181701 COVER BACK (DLT-20J1/J3 HIPS BK) 4852181701 COVER BACK (DLT-20J1/J3 HIPS BK)
M211A 7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK
3CR)
7172401452 SCREW TAPPTITE (TT2 TRS 4X14 MFZN BK 3CR)
M212 4852176401 COVER STAND BASE (20J1 (BK9604BP)) 4852176411B COVER STAND BASE (20J3 BK9604BP)
M212A
M213 4855218800 PLATE BASE STAND (SECC T2.2) 4855218800 PLATE BASE STAND (SECC T2.2)
M213A 4857942702 RUBBER (BK PHI 19X2.0T HRC 70-75) 4857942702 RUBBER (BK PHI 19X2.0T HRC 70-75)
M213B 7115400851 SCREW TAPPING (FLT 4X8 MFZN 3CR) 7115400851 SCREW TAPPING (FLT 4X8 MFZN 3CR)
M231 485233300101 PANEL CTRL (20J1 HIPS BK) 485233300101 PANEL CTRL (20J1 HIPS BK)
M381 4853833501 FRAME MAIN PCB (DLT-20J1/J3 SECC T0.8
(AUO))
4853833501 FRAME MAIN PCB (DLT-20J1/J3 SECC T0.8 (AUO))
M381A 7178300851 SCREW TAPPTITE (TT2 WAS 3X8 MFZN 3CR) 7178300851 SCREW TAPPTITE (TT2 WAS 3X8 MFZN 3CR)
M381B 7178300851 SCREW TAPPTITE (TT2 WAS 3X8 MFZN 3CR) 7178300851 SCREW TAPPTITE (TT2 WAS 3X8 MFZN 3CR)
M381C
M381D
M381E 7008301451 SCREW MACHINE (M-WAS 3X14 MFZN 3CR) 7008301451 SCREW MACHINE (M-WAS 3X14 MFZN 3CR)
M381F
M382
Different part list for models
