19
CHOOSE THE BLADE
Choose a suitable recommended cutting attachment
according to the object to be cut.
When replacing blade always be sure to use products, which have been
certified by your supplier.
WARNING
When sharpening, removing, or reattaching the blade, be sure to wear thick,
sturdy gloves and use only proper tools and equlpment to prevent lnjury.
SETUP
(1) Cover
(2) Holder
1. Detach the line head assembly completely.
2. Put on the blade, making the marked side face the holder, pul on the
outer holders, and lasten the blade with the blade nut.
IMPORTANT
Change the cutting attachment guard, which is suitable for the metal blade.
TIGHTENING TORQUE: 1 ·5 - 2·º N.m.
(0.15- 0.2 kg.m.)
8. OPERATION (OPTIONAL BLADE USAGE)
