60
¡ DSB-070L/DSB-091L /DSB-121L(After) PART LIST(OUTDOOR UNIT)
No PART CODE PART NAME Q'TY SPEC REMARK
1
3100300511
PAN BASE 1
SECC T1.2 070L/091L
3100300531 SECC T1.2 121L
3107101180 M8 x L47.5
070L(LG COMP. QB125PL12B)
2 COMP. BOLT 3
091L(LG COMP. QK164PN12F)
3106000900 M8XL46.5
091L(DW COMP. RBB090A001)
121L(DW COMP. RCB120A001)
3 3102100800 FOOT 2 SECC T1.2 070L/091L/121L
3107101110
070L(LG COMP. QB125PL12B)
4 COMP. GROMMET 3 EPDM
091L(LG COMP. QK164PN12F)
3108134AEO
091L(DW COMP. RBB090A001)
121L(DW COMP. RCB120A001)
3107101100 QB125PL12B 070L
5
3107101800
COMPRESSOR ASS’Y 1
QK164PN12F
091L
3RC0020JE0 RBB090A001
3100030CE0 RCB120A001 121L
6
3100054800
CONDENSER ASS’Y 1 L465xW208.5xH508
070L/091L
3100014110 121L
7 3100602200 BRACKET SERVICE 1 SECC T1.2
8 3105400700 SERVICE VALVE 1 1/2¡¨
9 3105400800 SERVICE VALVE 1 1/4¡¨
10
3100006400
PIPE COND IN ASS’Y 1 C1220T
070L/091L
3104410710 121L
11 3104412800 PIPE COND OUT ASS’Y 1 C1220T 121L
12
3104411411
PIPE OUTLET 1 C1220T
070L/091L
3104411420 121L
3100055100
070L(LG COMP. QB125PL12B)
13
3100055110
PIPE SUCTION ASS’Y 1 C1220T
091L(LG COMP. QK164PN12F)
3100055300
091L(DW COMP. RBB090A001)
3100020710
121L(DW COMP. RCB120A001)
3100055200
070L(LG COMP. QB125PL12B)
14
3100055210
PIPE DISCHARGE ASS’Y 1 C1220T
091L(LG COMP. QK164PN12F)
3100055200
091L(DW COMP. RBB090A001)
3100020610
121L(DW COMP. RCB120A001)
3100014200
070L(LG COMP. QB125PL12B)
3100061820
C1220T
091L(LG COMP. QK164PN12F)
15
3100061810
PIPE FILTER ASS’Y 1
091L(DW COMP. RBB090A001)
3100014200
121L(DW COMP. RCB120A001)
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
To Next Page
