¡ DSB-070L/DSB-091L /DSB-121L(After) PART LIST(OUTDOOR UNIT)
No PART CODE PART NAME Q'TY SPEC REMARK
16 3102501100 GUIDE SUPPORT 1 SECC T1.2
17 3102402600 GRILLE CONDENSER 1 P.E. 660x525.5xT3.5
18 3100601901 BRACKET MOTOR 1 SBHG1 T1.2
3108004000 IC-9625DWLF5A 070L
19 3108004100 MOTOR ODU 1 IC-9630DWLF5A 091L
3108000800 IC-9430DWLC5B 121L
20 3101801000 FAN PROPELLER 1
ABS+G.F20% (BLACK)
21 7400208411 WASHER PLAIN 1 PW-2-8 MFZN
22 7392800011 NUT LOCK 1 M8 x P1.25 MFZN
23 3104201900 PANEL CONTROL 1 SBHG1 T0.8
24 3108912300 TERMINAL BLOCK 1 SN-DBW-03P
3109501201 1.8+25µF 400VAC
070L(LG COMP. QB125PL12B)
25 CAPACITOR DUAL 1
091L(LG COMP. QK164PN12F)
3109502010 1.8+30µF 400VAC
091L(DW COMP. RBB090A001)
3109500700 3.5+25µF 400VAC
121L(DW COMP. RCB120A001)
26 3101201100 CLAMP CAPACITOR 1 SBHG1 T1.0
27 3101202000 CLAMP CORD 1 NYLON
28 3100801200 CABINET FRONT 1 SECC T0.8
29 3102402500 GRILLE DISCHAGE 1 Ø425.5
30 3103502210 LABEL BRAND 1 P.C.FILM T0.4
31 3100801300 CABINET SIDE 1 SECC T0.8
32 3104201800 PANEL TOP 1 SECC T0.8
33 3102600300 HANDLE 1 A.E.S. T2.5 (WH104A)
34 3102101000 FOOT CUSHION 4
NBR (HARDNESS 45°¡ 5°)
35 7112401211 TAPPING SCREW 11 T1S TRS 4X12 MFZN
36 7112401214
TAPPING SCREW+PVC WASHER
29 T1S TRS 4X12 MFZN
37
7112401211
TAPPING SCREW 4
T1S TRS 4X12MFZN 070L/091L
7112402011 T1S TRS 4X20 MFZN 121L
38 7111301611 TAPPING SCREW 2 T1S PAN 3X16 MFZN
39 7112403011 TAPPING SCREW 3 T1S TRS 4X30 MFZN
40 7S432X40A1 SPECIAL SCREW 1
TT3 TRS SE 4X8 MFZN
41 7112401614
TAPPING SCREW+PVC WASHER
5 T1S TRS 4X16 MFZN
To Next Page
