No PART CODE PART NAME Q'TY SPEC REMARK
1 3100300501 PAN BASE 1 SECC
2 3106000900 COMP BOLT 3 M8 X L46.5 MFZN
3 3102100800 FOOT 2 SECC
4 3108134AE0 GROMMET 3 EPDM
5 3100030CE0 COMPRESSOR ASS'Y 1 RCB120A001
6 7400208411 WASHER PLANE 4 M8.4 X 0.D22 X T1.6
7 7392800011 NUT LOCK 4 M8 X P1.25 MFZN
8 3100014100 CONDENSER ASS'Y 1
9 3100015100 BRACKET SERVICE ASS'Y 1
10 3105400700 SERVICE VALVE 1 1/2"
11 3105400800 SERVICE VALVE 1 1/4"
12 7347602011 BOLT HEX 4 M6 X L20 MFZN
13 3100020600 PIPE DISCHARGE ASS'Y 1 C1220T
14 3100020700 PIPE SUCTION ASS'Y 1 C1220T
15 3100014200 FILTER ASS'Y 1 C1220T
16 3100800600 CABINET BACK 1 ABS or AES
17 3104503800 PLATE PARTITION 1 SBHG1
18 3100601901 BRACKET MOTOR 1 SBHG1
19 3108000800 MOTOR ODU 1 IC-9430DWLC5A
20 3101801000 FAN PROPELLER 1 ABS+G.F20%
21 3100015400 PANEL CONTROL ASS'Y 1
21-1 3104201301 PANEL CONTROL 1 SBHG1
63
¡ DSB-121L(Before) PART LIST(OUTDOOR UNIT)
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
