64
No PART CODE PART NAME Q'TY SPEC REMARK
21-2 3109500700 CAPACITOR DUAL 1 3.5+25µF 400VAC
21-3 3101201100 CLAMP CAPACITOR 1 SBHG1
21-4 3108900900 TERMINAL BLOCK 1 323-HDS103
21-5 3103800300 LOCK TWIST 1 DATL-250
21-6 3101202000 CLAMP CORD 1 NYLON
21-7 7111301611 TAPPING SCREW 1 TIS PAN 3 X 16 MFZN
21-8 7112403011 TAPPING SCREW 3 TIS TRS 4 X 30 MFZN
22 3100800701 CABINET SIDE 1 ABS or AES
23 3100800501 CABINET FRONT 1 ABS or AES
24 3104201201 PANEL ORIFICE 1 P.P
25 3101401900 COVER GRILLE 1 ABS or AES
26 3104201100 PANEL TOP 1 ABS or AES
27 3102600300 HANDLE 1 ABS or AES
28 3102100700 FOOT CUSHTON 4 NBR
29 7112401211 TAPPING SCREW 19
T1S TRS 4 X 12 MFZN
30 7112402011 TAPPING SCREW 4
T1S TRS 4 X 20 MFZN
31 3106001600 SPECIAL SCREW 1
T2 4 X 16 MFNI LOCKING
32 7112401614 TAPPING SCREW 4
T1S TRS 4 X 16 MFNI+PVC/W
33 7S422X40B1 SPECIAL SCREW 4
TT2 TRS SE 4 X 12 MFZN
34 7112401214 TAPPING SCREW 12
TIS TRS 4 X 12 MFZN+PVC/W
¡ DSB-121L(Before) PART LIST(OUTDOOR UNIT)
