INDOOR UNIT
■ Remote Control Signal Receiver
This place is the part to receive the signal if it receive
the signal, you can hear the signal “beep”.
■ When the remote controller is lost or out-
of-order, push the emergency button
(EMERGENCY) to operate by hand.
Open the front panel on emergency operating.
Remocon switch is usually used with remote con-
troller.
Indoor Unit Display Switch Panel
Timer (Green)
Lights-on during the time
of reservation mode.
Quick (Green)
Lights-on during the time
of Quick Mode.
ON (Red)
Lights-on
during the operation
Air clean (Green)
Lights-on
during the operation
ON AIR
CLEAN
QUICK TIMER
EMERGENCY REMOTE
EMERGENCY REMOTE
