48
* DSB-240AH-R/240PH-R
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3108003800 220/50/60Hz 1
Fan Motor Capacitor 3106902400 2.0uF 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Transformer 5EPV050120 230V/50Hz 1
Stepping Motor 3108007600 GSP-24RW-062 1
Terminal Block 3108912320 SN-DBW-4P 1
Voltage Generator
3113701800 5.6KV 1 DSB-240AH-R
3113701500 5.6KV 1 DSB-240PH-R
Dust Collector 3113700500 1
Compressor 3100068201 AWG-5530EXC 1
Fan Motor 3108001500 220V/60Hz 1
Dual Capacitor 3100902500 5/30µF 400VAC 1
Terminal Block 3108912320 SN-DBW-4P 1
Reversing Valve 3105400310 CHV-0201 1
Solenoid coil 3109700110 CHV-01AJ506B1 1
Outdoor
Unit
Indoor
Unit
