CP-520V Service Manual
6. SERVICE PARTS LIST
6.1 DTX-21G2FZP-SB
z_loc z_parts_code parts_name parts_descr remark
z_loc z_parts_code parts_name parts_descr remark
ZZ100 PTACPWE519 ACCESSORY AS DTX-21G2FZS-SB
12000 48B5849C1001 TRANSMITTER REMOCON R-49C10
13000 4850Q00910 BATTERY AAA R03 SUPERGARD/ROCKET
14000 4858213801 BAG INSTRUCTION L. D. P. E. T0. 05X250X400
ZZ120 PTBCSHE519 COVER BACK AS DTX-21G2FZS-SB
M211 4852172311G COVER BACK 21G2 HIPS GY8301A
M541 4855415800 S/PLATE 150ART P/E FILM (C/TV)
M542 4855800022P1 LABEL SERIAL ART 90 55X34
ZZ130 PTCACAE524 CABINET AS DTX-21G2FZP-SB
20 2193110002 SOLDER WIRE SN-3.0AG-0.5CU (DHB-RMA3)
40 4856812001 TIE CABLE NYLON66 DA100
M191 4851954300 DOOR AS 21G2 GY340A+SV128BP/PC
M201A 4856017703 SCREW CRT FIX 5X30 L80 BK 3CR
M201B 4856215402 WASHER RUBBER 20’’
M201C 4856017710 SCREW CRT FIX 5X30 L190 BK 3CR
M211A 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M211B 7178301052 SCREW TAPPTITE TT2 WAS 3X10 MFZN BK 3CR
M231A 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
M481 4854869711 BUTTON POWER 21G2 ABS GY340A+SV128BP
M481A 4856715600 SPRING 14A5 SWPA
M501 485506202001 DECO CTRL 21G2 PC T0.25
M561 48556192SD02 MARK BRAND “DAEWOO 68MM (20””21””)”
M781 4857817610 CLOTH BLACK “300 MM 20”””
M791 4857923300 DOOR LOCK LA701 (KIFCO)
PWC1 4859903110 CORD POWER W/F 6-LO (LOMAX)
SP01A 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
SP02A 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK 3CR
V901 4859640060 “CRT (THOMSON 21””)” A51ELD032X001
ZZ131 58G0000177 COIL DEGAUSSING DC-21SF AL
ZZ132 48519A7610 CRT GROUND AS 2103S-1015-1P
ZZ200 PTFMSJY21G2S MASK FRONT AS DTY-21G2 SV128BP
M231 4852330711 PANEL FRONT 21G2 HIPS BK+GY8204BP
M801 4852090511S MASK FRONT 21G2 GY340A
ZZ210 PTSPPWE519 SPEAKER AS DTX-21G2FZS-SB
P601A 4850704S28 CONN AS YH025-04+35089+ULW=600
SP01 4858317410 SPEAKER SP-58126FC
SP02 4858317410 SPEAKER SP-58126FC
ZZ290 PTMPMSE524 PCB MAIN MANUAL AS DTX-21G2FZP-SB
10 2193110001 SOLDER WIRE SN-3.0AG (NP303T) 3.0
20 2193110002 SOLDER WIRE SN-3.0AG-0.5CU (DHB-RMA3)
30 2291050617P FLUX SOLDER CF-329D
40 2291050314 FLUX SOLVENT IM-1000
C403 CMYH3C662H C MYLAR 1.6KV BUP 6600PF H
C407 CMXF2E224J C MYLAR 250V MPU 0.22MF J
C408 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C626 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV
C804 CEYD2G181D C ELECTRO 400V FHS 180MF
C805 CCXR3D681K C CERA 2KV R 680PF K 125C
C811 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
C812 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C813 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C814 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C816 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C818 CEXF1C222V C ELECTRO 16V RSS 2200MF(13X25)TP
C827 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
D707 DLH3PRG03- LED BLOCK LH-3P-RG-03
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51
HP01 4859102130 JACK EARPHONE YSC-1537
I301 1LA78040— IC VERTICAL LA78040
I301A 4857027100 HEAT SINK SPCC T1.0+SN
I301B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I502 124LC16B1B IC MEMORY 24LC16B1B
I601 1LA42032E- IC AUDIO AMP LA42032-E
I601A 4857024401 HEAT SINK AL EX (NO ANODIZING)
I601B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I801 1STRW6754- IC POWER STR-W6754
I801A 4857024600 HEAT SINK AL EX B/K
I801B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
I802 1LTV817C— IC PHOTO COUPLER LTV-817C
I804 1LE33CZ—- IC REGULATOR LE33CZ
IF01 1441VF6—- IC PREAMP 441VF6
JPA01 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA02 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA03 4859108450 JACK PIN BOARD YSC03P-4120-14A
L401 58H0000020 COIL H-LINEARITY L-76(76.5UH)
LF801 5PLF24A1— FILTER LINE LF-24A1
P401 4850705N14 CONNECTOR BIC-05T-25T+ULW=500
P402 4859242420 CONN WAFER YFW800-04
P501 4850705N14 CONNECTOR BIC-05T-25T+ULW=500
P601 4859231720 CONN WAFER YW025-04
P701 4859231720 CONN WAFER YW025-04
P801 4859242220 CONN WAFER YFW800-02
P802 4859242220 CONN WAFER YFW800-02
Q402 TST1803DFH TR HORI ST1803DFH
Q402A 4857027201 HEAT SINK AL T1.0
Q402B 7174301051 SCREW TAPPTITE TT2 RND 3X10 MFZN 3CR
R311 RS02Y229JS R M-OXIDE FILM 2W 2.2 OHM J SMALL
R406 RS02Y103JS R M-OXIDE FILM 2W 10K OHM J SMALL
R407 RS02Y102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R411 RS02Y109JS R M-OXIDE FILM 2W 1 OHM J SMALL
R800 RX07B229JP R CEMENT 7W 2.2 OHM J BEN 15MM 4P
R801 DTC7R0M270 POSISTOR PDC7R0MP6B7Z81C
R805 RS02Y228JS R M-OXIDE FILM 2W 0.22 OHM J SMALL
SCT01 4859304130 SOCKET CRT ISHG93S
SW801 5S40101143 SW PUSH PS3-22SP (P.C.B)
T401 50D10A3—- TRANS DRIVE TD-10A3
T402 50H0000310 FBT LTC-565
T801 50M3541C4- TRANS SMPS TSM-3541C4
U100 4859730330 TUNER VARACTOR TAEM-G010D
X501 5XJ24R576E CRYSTAL QUARTZ HC-49/S 24.576MHZ 30PPM
Z101 5PK3953M— FILTER SAW K3953M
Z102 5PK9650M— FILTER SAW K9650M
ZZ200 PTMPJBE520 PCB MAIN EYE LET AS DTX-21U7FZS
E01 4856310600 EYE LET BSR 2.3(R2.3) BIG
E02 4856310600 EYE LET BSR 2.3(R2.3) BIG
E03 4856310600 EYE LET BSR 2.3(R2.3) BIG
E05 4856310600 EYE LET BSR 2.3(R2.3) BIG
E06 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E08 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E09 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E10 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E11 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E12 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E13 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E14 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E15 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E16 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E17 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E18 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E19 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E20 4856310300 EYE LET BSR T0.2 (R1.6) SMALL
E21 4856310600 EYE LET BSR 2.3(R2.3) BIG
E22 4856310600 EYE LET BSR 2.3(R2.3) BIG
E23 4856310600 EYE LET BSR 2.3(R2.3) BIG
E24 4856310600 EYE LET BSR 2.3(R2.3) BIG
E25 4856310600 EYE LET BSR 2.3(R2.3) BIG
ZZ200 PTMPJ2E520 PCB CHIP MOUNT B AS DTX-21U7FZS
I501 1TDA20HF01 IC MICOM FLASH TDA12020H1/N1/F01
ZZ200 PTMPJRE520 PCB MAIN RADIAL AS DTX-21U7FZS
C101 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C102 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C105 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C106 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C302 CEXF1H101V C ELECTRO 50V RSS 100MF (8*11.5) TP
C305 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C306 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C307 CMXM2A104J C MYLAR 100V 0.1MF J TP
C401 CMXM2A104J C MYLAR 100V 0.1MF J TP
C402 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
Caution : In this Service Manual, some parts can be changed for improving, their performance
without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center(http://svc.dwe.co.kr)
