CP-520V Service Manual
z_loc z_parts_code parts_name parts_descr remark
z_loc z_parts_code parts_name parts_descr remark
C405 CCXB2H561K C CERA 500V B 560PF K (TAPPING)
C406 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3*11) TP
C409 CXSL2H470J C CERA 500V SL 47PF J (TAPPING)
C410 CMXM2A104J C MYLAR 100V 0.1MF J TP
C501 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C502 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C505 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C507 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C508 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C509 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C510 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C511 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C513 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C514 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C515 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C516 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C517 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C518 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C519 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C520 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C521 CMXM2A222J C MYLAR 100V 2200PF J TP
C522 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C524 CMXM2A682J C MYLAR 100V 6800PF J TP
C525 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C526 CMXL1J224J C MYLAR 63V MEU 0.22MF J TP
C527 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C528 CCXF1H223Z C CERA 50V F 0.022MF Z (TAPPING)
C529 CMXL1J154J C MYLAR 63V MEU 0.15MF J
C534 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C535 CMXL1J474J C MYLAR 63V 0.47MF MKT
C536 CMXL1J474J C MYLAR 63V 0.47MF MKT
C537 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C538 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C539 CMXM2A332J C MYLAR 100V 3300PF J TP
C540 CMXM2A473J C MYLAR 100V 0.047MF J TP
C542 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C543 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C545 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C547 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C548 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C549 CMXL1J474J C MYLAR 63V 0.47MF MKT
C552 CMXL1J474J C MYLAR 63V 0.47MF MKT
C553 CMXL1J474J C MYLAR 63V 0.47MF MKT
C554 CMXL1J474J C MYLAR 63V 0.47MF MKT
C556 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C558 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C560 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C561 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C562 CMXM2A104J C MYLAR 100V 0.1MF J TP
C563 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C567 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C568 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C569 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C574 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C576 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C577 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C579 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C581 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C601 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C602 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C603 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C609 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C610 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C611 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C625 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5*11) TP
C802 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C806 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C807 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C815 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C817 CEXF1A471V C ELECTRO 10V RSS 470MF(TAPPING)
C819 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3*11) TP
C820 CMXM2A104J C MYLAR 100V 0.1MF J TP
C821 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C824 CEXF1A471V C ELECTRO 10V RSS 470MF(TAPPING)
C833 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C834 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C835 CEXF1C471V C ELECTRO 16V RSS 470MF (10X12.5)TP
C904 CCXB3A271K C CERA 1KV B 270PF K (TAPPING)
CA10 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I803 1K1A431B— IC REGULATOR(SHUNT) KIA431B 2.495V 0.5% TO-92
I805 1K1A431B— IC REGULATOR(SHUNT) KIA431B 2.495V 0.5% TO-92
L517 5CPX479K— COIL PEAKING 4.7UH K RADIAL
L518 5CPX479K— COIL PEAKING 4.7UH K RADIAL
L519 5CPX479K— COIL PEAKING 4.7UH K RADIAL
L802 58CX430599 COIL CHOKE AZ-9004Y 940K TP
Q101 T2SC5343Y- TR 2SC5343Y
Q401 TKTC3207— TR KTC3207
Q501 T2SC5343Y- TR 2SC5343Y
Q502 T2SA1980Y- TR 2SA1980Y
Q503 T2SC5343Y- TR 2SC5343Y
Q504 T2SA1980Y- TR 2SA1980Y
Q506 T2SC5343Y- TR 2SC5343Y
Q507 T2SA1980Y- TR 2SA1980Y
Q508 T2SC5343Y- TR 2SC5343Y
Q513 T2SA1980Y- TR 2SA1980Y
Q514 TH2N7000— TR H2N7000
Q515 TH2N7000— TR H2N7000
Q601 T2SA1980Y- TR 2SA1980Y
Q602 T2SC5343Y- TR 2SC5343Y
Q801 T2SC5343Y- TR 2SC5343Y
Q802 T2SC5343Y- TR 2SC5343Y
Q803 T2SC5343Y- TR 2SC5343Y
Q804 TKTA1270Y- TR KTA1270Y
Q805 TKTA1270Y- TR KTA1270Y
Q806 T2SC5343Y- TR 2SC5343Y
Q807 TKTA1270Y- TR KTA1270Y
Q808 T2SC5343Y- TR 2SC5343Y
Q809 TKTC3202Y- TR KTC3202Y
Q901 TKTC3207— TR KTC3207
Q902 TKTC3207— TR KTC3207
Q903 TKTC3207— TR KTC3207
Q904 TBF420—— TR BF420
Q905 TBF420—— TR BF420
Q906 TBF420—— TR BF420
Q907 TBF421—— TR BF421
Q908 TBF421—— TR BF421
Q909 TBF421—— TR BF421
R823 RN02B390JS R METAL FILM 2W 39 OHM J SMALL
R836 RN02B390JS R METAL FILM 2W 39 OHM J SMALL
R837 RN02B100JS R METAL FILM 2W 10 OHM J SMALL
R838 RN02B240JS R METAL FILM 2W 24 OHM J SMALL
R904 RN02B123JS R METAL FILM 2W 12K OHM J SMALL
R905 RN02B123JS R METAL FILM 2W 12K OHM J SMALL
R906 RN02B123JS R METAL FILM 2W 12K OHM J SMALL
R910 RN01B680JS R METAL FILM 1W 68 OHM J SMALL
SW700 5S50101090 SW TACT SKHV17910A
SW701 5S50101090 SW TACT SKHV17910A
SW702 5S50101090 SW TACT SKHV17910A
SW703 5S50101090 SW TACT SKHV17910A
SW704 5S50101090 SW TACT SKHV17910A
Z603 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z604 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z605 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z606 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z607 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z608 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z609 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z610 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z611 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z612 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
ZZ200 PTMPJAE520 PCB MAIN AXIAL AS DTX-21U7FZS
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M (WITH GLUE)
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M (W/O GLUE)
A001 4859813693 PCB MAIN CP-520V (DTX) 330X246(1X1)T1.6
C107 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C123 CCZL1H472K C CERA 50V B 4700PF K AXL (1608)
C301 CCZJ1H103Z C CERA 50V F 0.01MF Z AXL (1608)
C310 CCZJ1H473Z C CERA 50V F 0.047MF Z AXL (1608)
C412 CCZJ1H473Z C CERA 50V F 0.047MF Z AXL (1608)
C503 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C504 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C512 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C523 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C530 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C531 CCZJ1H103Z C CERA 50V F 0.01MF Z AXL (1608)
C532 CCZJ1H103Z C CERA 50V F 0.01MF Z AXL (1608)
C533 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C541 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C544 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
