49
CP-520V Service Manual
z_loc z_parts_code parts_name parts_descr remark
z_loc z_parts_code parts_name parts_descr remark
C546 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C550 CCZJ1H103Z C CERA 50V F 0.01MF Z AXL (1608)
C551 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C555 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C557 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C564 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C565 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C566 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C575 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C578 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C589 CCZL1H472K C CERA 50V B 4700PF K AXL (1608)
C590 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C591 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C592 CCZJ1H103Z C CERA 50V F 0.01MF Z AXL (1608)
C605 CBZR1C472M C CERA Y5R 16V 4700PF M AXIAL
C606 CBZR1C472M C CERA Y5R 16V 4700PF M AXIAL
C612 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C613 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C614 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C615 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL (1608)
C616 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C617 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C618 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C619 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C701 CCZJ1H103Z C CERA 50V F 0.01MF Z AXL (1608)
C808 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
C809 CCZJ1H473Z C CERA 50V F 0.047MF Z AXL (1608)
C810 CCZB1H821K C CERA 50V B 820PF K (AXIAL)
C828 CCZB1H561K C CERA 50V B 560PF K (AXIAL)
C901 CCZB1H331K C CERA 50V B 330PF K (AXIAL)
C902 CCZB1H331K C CERA 50V B 330PF K (AXIAL)
C903 CCZB1H331K C CERA 50V B 330PF K (AXIAL)
CA01 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA02 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA03 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA04 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA05 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA06 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA28 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
D101 DUZ33B—— DIODE ZENER UZ-33B
D102 DBA282—— DIODE BA282
D103 D1N4148—- DIODE 1N4148 (TAPPING)
D104 DTZX3V9B— DIODE ZENER TZX3V9B (TAPPING)
D301 D1N4004S— DIODE 1N4004S
D302 D1N4937G— DIODE 1N4937G
D303 D1N4937G— DIODE 1N4937G
D401 D1N4937G— DIODE 1N4937G
D402 D1N4148—- DIODE 1N4148 (TAPPING)
D403 D1N4148—- DIODE 1N4148 (TAPPING)
D404 D1N4937G— DIODE 1N4937G
D501 D1N4148—- DIODE 1N4148 (TAPPING)
D502 DTZX3V9B— DIODE ZENER TZX3V9B (TAPPING)
D503 DTZX3V9B— DIODE ZENER TZX3V9B (TAPPING)
D522 DTZX3V9B— DIODE ZENER TZX3V9B (TAPPING)
D523 DTZX3V9B— DIODE ZENER TZX3V9B (TAPPING)
D524 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
D525 DTZX6V2—- DIODE ZENER TZX6V2B (TAPPING)
D526 DTZX6V2—- DIODE ZENER TZX6V2B (TAPPING)
D527 DTZX6V2—- DIODE ZENER TZX6V2B (TAPPING)
D601 D1N4148—- DIODE 1N4148 (TAPPING)
D602 D1N4148—- DIODE 1N4148 (TAPPING)
D801 DLT2A05G— DIODE LT2A05G
D802 DLT2A05G— DIODE LT2A05G
D803 DLT2A05G— DIODE LT2A05G
D804 DLT2A05G— DIODE LT2A05G
D805 D1N4937G— DIODE 1N4937G
D806 D1N4937G— DIODE 1N4937G
D807 D1N4148—- DIODE 1N4148 (TAPPING)
D808 DTZX6V2—- DIODE ZENER TZX6V2B (TAPPING)
D809 DRGP15J—- DIODE RGP15J
D811 D1N4937G— DIODE 1N4937G
D812 DRGP15J—- DIODE RGP15J
D817 DRGP15J—- DIODE RGP15J
D817B DRGP15J—- DIODE RGP15J
D818 DTZX4V3B— DIODE ZENER TZX4V3B (TAPPING)
D819 DRGP15J—- DIODE RGP15J
D820 DTZX2V4A— DIODE ZENER TZX2V4A (TAPPING)
D821 DTZX2V4A— DIODE ZENER TZX2V4A (TAPPING)
D902 D1N4148—- DIODE 1N4148 (TAPPING)
DA01 85801060GY WIRE COPPER 1/0.6 TIN COATING
DA02 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA03 85801060GY WIRE COPPER 1/0.6 TIN COATING
DA04 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA06 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA08 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA09 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA10 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA11 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA13 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA14 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA15 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA16 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA20 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA21 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DA22 DTZX5V6B— DIODE ZENER TZX5V6B (TAPPING)
DF01 DTZX3V9B— DIODE ZENER TZX3V9B (TAPPING)
J001 85801060GY WIRE COPPER 1/0.6 TIN COATING
J002 85801060GY WIRE COPPER 1/0.6 TIN COATING
J003 85801060GY WIRE COPPER 1/0.6 TIN COATING
J004 85801060GY WIRE COPPER 1/0.6 TIN COATING
J005 85801060GY WIRE COPPER 1/0.6 TIN COATING
J006 85801060GY WIRE COPPER 1/0.6 TIN COATING
J007 85801060GY WIRE COPPER 1/0.6 TIN COATING
J008 85801060GY WIRE COPPER 1/0.6 TIN COATING
J009 85801060GY WIRE COPPER 1/0.6 TIN COATING
J010 85801060GY WIRE COPPER 1/0.6 TIN COATING
J011 85801060GY WIRE COPPER 1/0.6 TIN COATING
J012 85801060GY WIRE COPPER 1/0.6 TIN COATING
J013 85801060GY WIRE COPPER 1/0.6 TIN COATING
J014 85801060GY WIRE COPPER 1/0.6 TIN COATING
J015 85801060GY WIRE COPPER 1/0.6 TIN COATING
J016 85801060GY WIRE COPPER 1/0.6 TIN COATING
J017 85801060GY WIRE COPPER 1/0.6 TIN COATING
J018 85801060GY WIRE COPPER 1/0.6 TIN COATING
J019 85801060GY WIRE COPPER 1/0.6 TIN COATING
J020 85801060GY WIRE COPPER 1/0.6 TIN COATING
J021 85801060GY WIRE COPPER 1/0.6 TIN COATING
J022 85801060GY WIRE COPPER 1/0.6 TIN COATING
J023 85801060GY WIRE COPPER 1/0.6 TIN COATING
J024 85801060GY WIRE COPPER 1/0.6 TIN COATING
J025 85801060GY WIRE COPPER 1/0.6 TIN COATING
J026 85801060GY WIRE COPPER 1/0.6 TIN COATING
J027 85801060GY WIRE COPPER 1/0.6 TIN COATING
J028 85801060GY WIRE COPPER 1/0.6 TIN COATING
J029 85801060GY WIRE COPPER 1/0.6 TIN COATING
J030 85801060GY WIRE COPPER 1/0.6 TIN COATING
J031 85801060GY WIRE COPPER 1/0.6 TIN COATING
J032 85801060GY WIRE COPPER 1/0.6 TIN COATING
J034 85801060GY WIRE COPPER 1/0.6 TIN COATING
J035 85801060GY WIRE COPPER 1/0.6 TIN COATING
J037 85801060GY WIRE COPPER 1/0.6 TIN COATING
J038 85801060GY WIRE COPPER 1/0.6 TIN COATING
J039 85801060GY WIRE COPPER 1/0.6 TIN COATING
J040 85801060GY WIRE COPPER 1/0.6 TIN COATING
J041 85801060GY WIRE COPPER 1/0.6 TIN COATING
J043 85801060GY WIRE COPPER 1/0.6 TIN COATING
J044 85801060GY WIRE COPPER 1/0.6 TIN COATING
J045 85801060GY WIRE COPPER 1/0.6 TIN COATING
J046 85801060GY WIRE COPPER 1/0.6 TIN COATING
J047 85801060GY WIRE COPPER 1/0.6 TIN COATING
J048 85801060GY WIRE COPPER 1/0.6 TIN COATING
J049 85801060GY WIRE COPPER 1/0.6 TIN COATING
J050 85801060GY WIRE COPPER 1/0.6 TIN COATING
J051 85801060GY WIRE COPPER 1/0.6 TIN COATING
J052 85801060GY WIRE COPPER 1/0.6 TIN COATING
J053 85801060GY WIRE COPPER 1/0.6 TIN COATING
J054 85801060GY WIRE COPPER 1/0.6 TIN COATING
J055 85801060GY WIRE COPPER 1/0.6 TIN COATING
J056 85801060GY WIRE COPPER 1/0.6 TIN COATING
J057 85801060GY WIRE COPPER 1/0.6 TIN COATING
J058 85801060GY WIRE COPPER 1/0.6 TIN COATING
J059 85801060GY WIRE COPPER 1/0.6 TIN COATING
J061 85801060GY WIRE COPPER 1/0.6 TIN COATING
J062 85801060GY WIRE COPPER 1/0.6 TIN COATING
J063 85801060GY WIRE COPPER 1/0.6 TIN COATING
J065 85801060GY WIRE COPPER 1/0.6 TIN COATING
J066 85801060GY WIRE COPPER 1/0.6 TIN COATING
J067 85801060GY WIRE COPPER 1/0.6 TIN COATING
J068 85801060GY WIRE COPPER 1/0.6 TIN COATING
J069 85801060GY WIRE COPPER 1/0.6 TIN COATING
J070 85801060GY WIRE COPPER 1/0.6 TIN COATING
