ALIGNMENT INSTRUCTIONS
4-1.HORIZONTAL CENTER Adjustment
Select H CENTER item, adjust H CENTER data value to obtain proper horizontal centering of the internal cross
pattern at the left and right of the screen.
4-2.VERTICAL CENTER Adjustment
Select V CENTER item, adjust V CENTER data value to center the raster properly on the screen.
4-3.VERTICAL SIZE Adjustment
Select V SIZE item, adjust V SIZE data value to proper vertical size as figure 1.
5) WHITE BALANCE ADJUSTMENT(S8)
Enter the service mode and select service adjustment S8.
You can see the OSD as shown in below.
NOTE:
The color coordinator to x:265, y:270.
Use the CH up( ) or down ( ) buttons to select "CROSS BW" item.
Use the VOL up (
U
) button to select internal WHITE60 pattern.
Use the CH buttons to select RB/GB/BB item, adjust data until a good white.
Use the CH buttons to select "CROSS BW" item.
Use the VOL
U
button to select internal WHITE100 pattern.
Use the CH buttons to select RD/BD item, adjust data until a good white.
6) D.P(DIGITAL PRESET) ADJUSTMENT(S9)
SUBBRIGHTNESS Adjustment
Receive a good local channel.
Enter the service mode and select service adjustment S9
You can see the OSD as shown in below.
NOTE :
SUBBRIGHTNESS = RETMA PATTERN : 8%
Select Brightness item, adjust Brightness data value to obtain normal brightness level.
Sharpness
Fixed value = 000
Color
Fixed value = 035
Tint
Fixed value = 022
RD
GD 010
BD 063
GB
127 BB
127
CROSS BW
063
RB
127
D.P
Brightness 042
Sharpness 000
Color
022Tint
035
To Next Page
