-18-
SERVICE PARTS LIST
" " is safety component, so it must be used the same component.
CAUTION
ZZ100 48B4139A02 TRANSMITTER R-39A02 (AAA)
REMOCON
ZZ110 PTACPWH611 ACCESSORY AS DVQ-10H1FCN
00001 4850A02510 ANT ROD S3BW216B (L=600 MM)
00002 4850A00250 TRANS ANT MATCHING IMT-06
00003 4859910010 CORD CAR AS DLF-1033+SPT-2=2000
00004 48586083E1 MANUAL INSTRUCTION ENGLISH
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHH611 COVER BACK AS DVQ-10H1FCN
M211 4852162700 COVER BACK FR HIPS BK 10H1
ZZ130 PTPKCPH611 PACKING AS DVQ-10H1FCN
M801 4858061700 BOX CARTON SW-2 10H1
M811 4858100V00 PAD EPS 10H1
M822 4858219300 BAG P.E P.E FOAM T0.5X850X850
ZZ131 48519A6510 CRT GROUND NET 1001S-1015-1P
ZZ132 58G0000160 COIL DEGAUSSING DC-10S1
ZZ140 PTCACAH611 CABINET AS DVQ-10H1FCN
M201A 4856013355 SCREW CRT FIXING 25X50 WH
M201B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M201C 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M351 4853535600 HOLDER CORD NYROLN 66
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M682 4856812001 TIE CABLE NYLON66 DA100
V901 4859610440 CRT A23KQU22X02 P38
ZZ200 PTFMSJH611 MASK FRONT AS DVQ-10H1FCN
M191 4851948600 BUTTON CTRL 4954201+5548600 10H1
M191A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M201 4852082900 MASK FRONT FR HIPS BK 10H1
M281 4852817701 DOOR F/L ABS BK
M281A 4856723400 SPRING SWPB 0.4
ZZ210 PTSPPWH611 SPEAKER AS DVQ-10H1FCN
PA601 4850703S50 CONNECTOR YH025-03+35098+ULW=200
SP01 4858314310 SPEAKER SP-5070A01 3W 8 OHM
ZZ290 PTMPMSH611 PCB MAIN MANUAL AS DVQ-10H1FCN
DS03 DS15312H-- LED IR SI5312-H
DS03A 97P2339600 HOLDER IR ABS
DT01 DKLR114L-- LED KLR114L
DT02 DSD50RH51B LED SD50-RH51BGRW
I501 1LA76845N- IC LA76845N
I601 1TDA7267-- IC AUDIO AMP TDA7267
I803 PTJ2SW6900 HEAT SINK ASS`Y 1L7805CV-- + 7174300811
00001 1L7805CV-- IC REGULATOR L7805CV
0000A 4857026900 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I804 PTD2SW4617 HEAT SINK ASS`Y 1K78R05--- + 7174300811
I804 1K78R05--- IC REGULATOR KIA78R05PI
I804A 4857024617 HEAT SINK AL EX
I804B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I805 1K78R12--- IC REGULATOR KIA78R12PI
LOC PART CODE PART NAME DESCRIPTION REMARK
I805A 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
IS02 1K1A6801K- IC MOTOR DRIVER KIA6801K
IS03 1AT24C08PC IC AT24C08-10PC
IT01 1356VF6--- IC PREAMP 356VF6
JP01 4859109950 JACK PIN BOARD PH-JB-9710A
L102 58C5580019 COIL CHOKE TRF-9225 (0.55UH)
L110 58N0000042 COIL VCO TRF-V008
M191 4851941600 DECK AS DRN-9200
M351 4853535200 HOLDER LED FR HIPS BK
M381 4853818700 FRAME MAIN PCB FR HIPS BK 10H1
M381A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M721 4857249400 SHIELD TOP SECC T0.8
M721A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M721B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M721C 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M721D 97P0475800 CASE SHI PREAMP ET T0.4
PA402 4850708S06 CONNECTOR YH025-08+YBNT025-08=200
PA803 4850709S01 CONNECTOR YH025-09+YST025+ULW=200
PA901 4850705N10 CONNECTOR SMH250-05+YBNT250+ULW=300
PAS03 4850707V07 CONNECTOR 60-8283-3078-45+ULW=150
PAU01 4850706N07 CONNECTOR 60-8283-3068-45+USW=250
PS01 4859292320 CONN WAFER GF120-07S-TS
PS01A 4859200170 CONN FFC K-7X100-0.25
PS02 4859278220 CONN WAFER TKC-G10P-A1
PZ01 4859292220 CONN WAFER GF120-04S-TS-R
SS01 TST5811B-- TR PHOTO ST-5811(B-RANK)
SS01A 97P2343500 HOLDER TR ABS FR
SS02 TST5811B-- TR PHOTO ST-5811(B-RANK)
SS02A 97P2343500 HOLDER TR ABS FR
SS03 4850S00001 SENSOR REEL SG-258S
SS04 4850S00001 SENSOR REEL SG-258S
SS05 4850S00003 SENSOR DEW SY-DS-3
SWS01 5SN0101Z20 SW DETECT JDS1105-6XD
TU01 5800000032 COIL OSC DE0-006
U102 4859721730 TUNER VARACTOR DT5-NF20F N
XS01 5XYR03276C CRYSTAL QUARTZ C-001R 32.768000KHZ 20PPM
XS02 5XJ16R000E CRYSTAL QUARTZ HC-49S 16.000000MHZ 30PPM
Z101 5PM1876D-- FILTER SAW M1876D
Z102 5PYXT4R5MB FILTER CERA XT 4.5MB
ZZ200 PTMPJ2H611 PCB CHIP MOUNT B AS DVQ-10H1FCN
CC103 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC104 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC107 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC108 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC109 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC113 HCQK809DCA C CHIP CERA 50V CH 8PF D 2012
CC114 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC115 HCBK152KCA C CHIP CERA 50V X7R 1500PF K 2012
CC118 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
LOC PART CODE PART NAME DESCRIPTION REMARK
✔ In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
