Daewoo DVQ-10H1FCN User Manual

-21-
SERVICE PARTS LIST
P601 485923162S CONN WAFER YW025-03 (STICK)
PS04 485923182S CONN WAFER YW025-05 (STICK)
R116 RS02Z159JS R M-OXIDE FILM 2W 1.5 OHM J SMALL
R117 RS02Z159JS R M-OXIDE FILM 2W 1.5 OHM J SMALL
R604 RS02Z339JS R M-OXIDE FILM 2W 3.3 OHM J SMALL
RS83 RS02Z100JS R M-OXIDE FILM 2W 10 OHM J SMALL
ZZ200 PTMPJRH611 PCB MAIN RADIAL AS DVQ-10H1FCN
C101 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C102 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
C105 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C106 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C110 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C111 CEXF1H108A C ELECTRO 50V RSM 0.1MF 4X7
C116 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C117 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C121 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C136 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C507 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C508 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C509 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C511 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C512 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
C517 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C518 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C519 CEXF1H478A C ELECTRO 50V RSM 0.47MF 4X7
C520 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C522 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C526 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C527 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C528 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
C529 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
C551 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C602 CEXF1H108A C ELECTRO 50V RSM 0.1MF 4X7
C604 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CS14 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CS17 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS28 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS30 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CS39 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS42 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CS51 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS52 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS57 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CS59 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS70 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CT01 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CU01 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CU04 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CU05 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CU07 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
CU16 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
CU19 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CU20 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CU21 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
LOC PART CODE PART NAME DESCRIPTION REMARK
CU22 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
CU23 CMXM2A223J C MYLAR 100V 0.022MF J TP
CU30 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CY01 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY06 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
CY07 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CY09 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CY10 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CY11 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY14 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CY15 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY16 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY17 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CY18 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY19 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
CY23 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CY26 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY27 CEXF1H229A C ELECTRO 50V RSM 2.2MF (4X7) TP
CY29 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY31 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY32 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CY37 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CY39 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CZ01 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
IS04 1K1A7033AP IC RESET KIA7033AP
IS05 1K1A7042AP IC REGULATOR KIA7042AP
LU02 5CPX101J-- COIL PEAKING PL 100UH J (TAPPING)
LU03 5CPX103J-- COIL PEAKING 10MH 5MM J RADIAL
LY03 5CPX560J-- COIL PEAKING 56UH J (RADIAL)
Q503 TKTA1266Y- TR KTA1266Y (TP)
Q504 TKTC3198Y- TR KTC3198Y
Q505 TKTC3198Y- TR KTC3198Y
Q601 TKTC3198Y- TR KTC3198Y
QS03 TKTC3198Y- TR KTC3198Y
QT01 TKTC3198Y- TR KTC3198Y
QT02 TKTC3198Y- TR KTC3198Y
QT03 TKTC3198Y- TR KTC3198Y
QT04 TKTC3198Y- TR KTC3198Y
QU01 TKRC102M-- TR KRC 102-M (TAPPING)
QU02 TKTA1266Y- TR KTA1266Y (TP)
QU03 TKTA1266Y- TR KTA1266Y (TP)
QU06 TKTC3202Y- TR KTC3202Y (TP)
QY01 TKTA1266Y- TR KTA1266Y (TP)
QY02 TKTA1266Y- TR KTA1266Y (TP)
SWT01 5S50101Z90 SW TACT THVV502GDA
SWT02 5S50101Z90 SW TACT THVV502GDA
SWT03 5S50101Z90 SW TACT THVV502GDA
SWT04 5S50101Z90 SW TACT THVV502GDA
SWT05 5S50101Z90 SW TACT THVV502GDA
SWT06 5S50101Z90 SW TACT THVV502GDA
SWT07 5S50101Z90 SW TACT THVV502GDA
SWT08 5S50101Z90 SW TACT THVV502GDA
SWT09 5S50101Z90 SW TACT THVV502GDA
SWT10 5S50101Z90 SW TACT THVV502GDA
LOC PART CODE PART NAME DESCRIPTION REMARK
