Daewoo DVQ-10H1FCN User Manual

-30-
IC DESCRIPTION
1. SYSTEM FEATURE
1) The system for TV/VCR tuning is Frequency Synthesis type.
2) VCR SERVO Controller is interior designed.
3) Closed Caption function is interior designed.
4) V-Chip function is interior designed.
5) On Screen Display function is interior designed.
6) Package : 100PIN QFP
7) Tuner (Pre-scaler) : IIC BUS
/PLL IC : TAU 6014-S (SIEMENS)
8) REMOCON : The IC of transmission (MITSUBISHI M50560)
9) EEPROM : 24AT08 (IIC BUS)
10)10-Local Key : A/D input control
(KEY 0 : REC, REW, PLAY, FF, STOP/EJECT)
(KEY 1 : POWER, CH UP/DOWN, VOL UP/DOWN)
11) Option S/W : Port A/D input Option check
12)IF/V/C/D IC : LA76845
13)VCR Y/C/A IC : LA71076AM(LA71076SM)
14)DECK MECHANISM : K-50MECHA
