89 P8(1) DRUM FG IN Drum Frequency Generator signal input.
Feed back Drum rotation speed.
90 DRUM PG IN Drum Pulse Generator signal input.
Feed back Drum rotation phase.
91 AMP REF IN Control pulse AMP reference input terminal.
92 AMP REF OUT Control pulse AMP reference output terminal.
93 P8(0) C AMP filter.
94 CTL- Input control pulse when playing.
95 CTL+ Output control pulse when recording.
96 AMP C AMP condenser.
97 CTL AMP OUT Check Control pulse.
98 Vcc AMP Vcc
Ever +5V (
±
0.5V).
99 Vcc ANALOG Vcc
Ever +5V (
±
0.5V).
100 P11(1) KEY 0 IN REC, REW, PLAY, FF, STOP/EJECT
Pin Terminal Name Explanation Remarks
IC DESCRIPTION Appendix
