4
§ ANT IN Terminal
Connect a TV aerial to this terminal.
§ RF OUTPUT Terminal
Connect to the aerial terminal of a TV receiver with the RF
Cable (provided.)
§łTEST SIGNAL SWITCH
In test signal mode, you can check channel accordance of
the TV and VCR.
§øRF OUTPUT CHANNEL ADJUSTMENT SCREW
In video playback mode, you can adjust more accurately
the RF OUTPUT for obtaining clean picture.
§œAUDIO IN SOCKET (PHONO)
§ßVIDEO IN SOCKET (PHONO)
§ AUDIO OUT SOCKET (PHONO)
§ VIDEO OUT SOCKET (PHONO)
§ DC JACK
Connect this Jack to DC Source (DC 12V)
31
POWER CORD
Connect this cord into the AC outlet.
§ §ł §œ §ß
31
§ §ø § § §
