Daewoo DWC-1011W - Tub Assembly Parts List - Part 1; Tub Assembly Component Details - Part 1

11
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
D01 BALANCER WEIGHT L 3616110600 PP, D-LU1011, 6.6KG 1
D02 SPECIAL SCREW 3616029400 SWCH 8.5X30 8
D03 BALANCER WEIGHT R 3616110500 PP, D-LU1011, 6.6KG 1
D04 CLAMP GASKET AS 3611207000 C-LU1011 1
D05 GASKET 3612325300 EPDM , WASH , D-LU1011 1 WASH
D06 GASKET 3612325400 EPDM , DRY , C-LU1011 1 DRY
D07 NOZZLE SHOWER 3618111200 PP 1
D08 CLAMP GASKET BUSHING 3611206800
GI 1.2T 1 DRY
D09 SPECIAL SCREW 3616029810 SWCH 6.5X45 4
D10 DUCT B AS 3610DUTL00 C-L E 1 DRY
D11 HOSE DRAIN *I 3613275200 EPDM D-LU1011 1
D12 CLAMP AS 3611203210 ID=61, WIRE+GUIDE+BOLT, GS 1
D13 CLAMP HOSE 3611204700 D26 1
D14 CLAMP HOSE 3611201401 HSW3,YW,D2.6,ID36,W44.5 1
D15 AIR TRAP 361A500101 PP 1
D16 HOSE AIR(PRESSURE) 3613266930 ID=4,OD=8, L=680MM(L-SERIES) 1
D17 DAMPER FRICTION 361A700110
70N AKS ST=170-260 DL=197.5 LOW NOISE 2
D18 DAMPER PIN 361A700200 AKS D=14.5 2
D19 TUB FRONT 3618830000 FRPP, C-LU1011 1
D20 SPRING SUSPENSION 3615116800 KGF 2
D21 SPECIAL SCREW 3616029800 SWCH 6.5X30 14
D22 SPECIAL SCREW 3616029500 SUS430 8*25 3
D23 LIFTER WASH 361A401300 PP,1PIECE,TWIST 3
D24 SCREW TAPPING 7122401408 T2S TRS 4X14 SUS,STS 3
D25 DRUM AS 3617012500 D-LU1011 1
D26 SPIDER AS 361A301200
D-LU1011 1
D27 WATER SEAL 361A600100 NBR 1
D28 SEALING TUB 3612321601 EPDM L1600(-0~ +10) 1
D29 FIXTURE HEATER 3612006700 SUS 1
D30 BEARING INNER 3616303100 6206Z 1
D31 DAMPER FRICTION 361A700130
60N AKS ST=170-260 DL=197.5 LOW NOISE 2
D32 DAMPER PIN 361A700200 AKS D=14.5 2
D33 TUB REAR AS 36100T1400 D-LU1011 1
