No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
D34 BALANCER WEIGHT T 3616110400 PP, C-LU1011, 2.48KG 1 DRY
D35 BALANCER WEIGHT T(WASH) 3616110700 PP, D-LU1011, 2.48KG 1 WASH
D36 SPECIAL SCREW 3616029400 SWCH 8.5X30 2
D37 CLAMP HOSE 3611204700 D26 1
D38 SPECIAL SCREW 3616007400 T2S TRS 4X10+24 2 OPTION
D39 UNIT BUBBLE GENERATOR 36189L4177
HIGH,PAD B,BL/WH,320,RP4,GUIDE O,SPONGE 200
1 OPTION
D40 HOSE VENT 3613267100 EPDM 1
D41 BEARING OUTER 3616303200 6205Z 1
D42 HEATER WASH 3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
D43 PIPE DUCT AS 3614414001 C-L PIPE DUCT+HOSE+CLAMP 1
D44 UNIT STATOR BLDC 36189L6200 AL,30T(28T),NMT 1
D45 SPECIAL BOLT AS 3616029900 SWCH M8 + SILOCK 6
D46 UNIT ROTOR BLDC 36189L6300 L'SERIES, NMT 1
D47 SPECIAL BOLT AS 3616029620 SWCH 10*30 S/W P/W NON-SEAL LOCK 1
