4. DRIVE SYSTEM
4
3. VÁLVULAS DE LLENADO
FRÍO : 3- VIAS
FRÍO, PRELAVADO, SECADO
5. PUERTA
SEGURO/ SWITCH
PUERTA DE CRISTAL
EMPAQUE
7. DRENADO
MOTOR DRENADO
VÁLVULA HOUSING
6. PARTES SECADO
CALEFACTOR : 1200W
VENTILADOR
MOTOR VENT. BLDC
TERMISTOR
TERMOSTAT
FUSIBLE, BI-METAL
SISTEMA CONDENSADOR
IMPULSOR VENTILADOR
-> CALEFACTOR
-> SENSOR TEMP.
-> 95℃OFF 87℃ON
IBISAGRA DE SEGURIDAD
