4
1. CONTROL
PCB PRINCIPAL
PCB FRONTAL
HARNESS
FILTRO DE RUIDO
CABLE DE PODER : 15A
2. PARTES DE ROTACIÓN
MOTOR BLDC
TAMBOR
COJINETE
SOPORTE
TINA
BALANCER
4. CALEFACTOR DE LAVADO
CALEFACTOR : 1000W
TERMISTOR
30 °C CONTORL FIJO
50, 60 °C CONTROL VARIABLE
8. SOPORTE
BASE
AMORTIGUADOR : 3(70N)
