Daewoo DWD-FD1413 - Disassembly Directions; Door Lock Switch Disassembly; Heater and Thermistor Removal

4. DIRECTION FOR DISASSEMBLY
16
DIRECTION FOR DISASSEMBLY
DOOR LOCK SWITCH
1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet.
HEATER AND THERMISTOR
1) Remove five screws on the COVER B and separate
the COVER B from washing machine.
2) Remove the connectors of the HEATER.
3) Remove two screws, and remove the door lock
switch.
