20
EXPLODE VIEW AND PARTS LIST
3612608700 ABS DWD-F1X11(2)
3612608710 ABS + SPRAY DWD-F1X13
3612608900 ABS DWD-F1X21(2)
3612608910 ABS + SPRAY DWD-F1X23
3612609700 ABS DWD-F1X31(2)
3612609710 ABS + SPRAY DWD-F1X33
A01 HANDLE CASE 3611148000 HIPS, D-FU124'S 1 DWD-F1X41(2)
(CASE HANDLE) DWD-F1X51(2)
3611148001 ABS + SPRAY DWD-F1X43
DWD-F1X53
3611149500 D-F'SERIES 6TH, ABS DWD-F1X61(2)
3611149510 ABS + SPRAY DWD-F1X63
3611149600 D-F'SERIES 7TH , ABS DWD-F1X71(2)
3611149610 ABS + SPRAY DWD-F1X73
A02 CASE DETERGENT 3611140300 PP 1
A03 CAP SOFTENER 3610916600 PP 1
A04 BOX INLET 3610526500 PP 1
A05 NOZZLE AS
3618103510 NOZZLE TOP + NOZZLE UNDER
1
COLD
3618103500 COLD+HOT
A06 SCREW TAPPING 7122402011 T2S TRS 4x20 MFZN 1
A07 CLAMP AS 3611203200 ID=60,WIRE+GUIDE+BOLT+NUT 1
A08 HOSE INLET 3613267200 EPDM U-TRAP 1
A09 CLAMP HOSE I 3611201400 HSW3, D2.6, MFZN, ID=38 1
A10 HOSE WATER SUPPLY 3613270900 EPDM, ID9.5, OD14.5, L=225 2(3) COLD(+HOT)
A11 CLAMP HOSE 3611205800 100H, ID=13.8 W=10.0 0.9T 4(6) COLD(+HOT)
3615414900 220-240V 2-WAY PP/BRACKET COLD VALVE
A12 VALVE INET 3615414910 220-240V 2WAY NYLON VDE
3615416821
220-240V.VDE.BITRON.2WAY + DR TECH
COLD VALVE(EU)
A13 VALVE INLET
3615414800 220-240V,50/60Hz,1WAY HOT VALVE
3615416720
220-240 50/60-1WAY,HOT,BITRON,VDE
HOT VALVE(EU)
A14 SCREW TAPTITE 7272400811 TT3 TRS 4X8 MFZN 2(4) COLD(+HOT)
A15 DECO CASE HANDLE
3611698000 D-F'SERIES 6TH ,ABS DWD-F1X6X
3611698400 D-F'SERIES 7TH , ABS DWD-F1X7X
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
1
1
1
