38
EXPLODE VIEW AND PARTS LIST
D01
BALANCER WEIGHT F L/R
3616106320 FRONT, 5.5kg 2
D02
SPECIAL SCREW(BALANCER)
3616029400 SWCH 8.5X30 8
D03 GASKET 3612321400 EPDM 1
D04 CLAMP GASKET AS 3611204520 HSW3,GS 1
D05 TUB *F 3618821010 FRPP FH7304GM 1
D06 SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 14
D07 FIXTURE HEATER 3612007300 SUS 0.7T 440°ø45 1
D08 DRUM SUB AS 3617004002 SUS 0.5T 1
D09 LIFTER WASH 361A400400 PP 3
361A400410 NANO OPTION
D10 SPIDER AS 361A300510 ALDC+SM45C 1
D11
SPECIAL SCREW(SPIDER)
3616029500 SUS430 8x25 3
D12 HOSE DRAIN 3613267300 EPDM 1
D13 CLAMP AS 3611203210 ID=60,WIRE+GUIDE+BOLT+NUT 1
D14 CLAMP HOSE I 3611201401 HSW3, D2.6, MFZN, D=38 1
D15 AIR TRAP 361A500101 PP 1
D16 CLAMP HOSE 3611204700 D26 1
D17 HOSE AIR 3613268600 ID=4, OD=8, L=700 1
D18 TUB REAR AS 36100E2U10 D-FD14 1
D18-1 TUB REAR 3618821110 FRPP FH7304GM 1 1
D18-2 BEARING HOUSING 3616303321 ALDC M8 TAP D-FD'S DOMESTIC 1
D19 BEARING OUTER 3616303200 6205Z FAG 1
D20 BEARING HOUSING 3616303321 ALDC M8 TAP D-FD'S DOMESTIC 1
D21 BEARING INNER 3616303100 6206Z FAG 1
D22 WATER SEAL 361A600100 NBR 1
D23
GASKET TUB (SEALING TUB)
3612321601 EPDM L=1600(-0,+10) 1
D24 DAMPER FRICTION 361A700120 120N, AKS, ST=170-160, DL=197.5 2
D25 DAMPER PIN 361A700200 AKS, D=14.5 2
D26 HOSE VENT 3613267100 EPDM 1
D27 CLAMP HOSE 3611204700 D26, wire-type 1
D28 UNIT STATOR BLDC 36189L4820 AL-16T 36SLOT 2SNESOR 1 DONGSU
36189L621A AL,DON1000W 18T 36POLE,NMT,PBT 1 NEWMOTECH
36189L621E
AL,DON1000W 18T 36POLE,ENTEK,NMT,PBT
1 NEWMOTECH
D29 SPECIAL BOLT AS 3616029920 SWCH M8+SILOCK, 35MM 6 DONGSU
3616029910 SWCH M8+SILOCK,49MM 6 NEWMOTECH
D30 UNIT ROTOR BLDC 36189L4910 MAGENT24 SERRATION 1 DONGSU
36189l6310 DON1000W SR-FERRITE12, 18T, NMT 1 NEWMOTECH
D32 HEATER WASH 3612802400 220V 2KW.1R0A721001.RW8TF.IRCA 1 DWD-FD'S(220V)
3612802410 230V 2KW.1R0A721002.RW8TF.IRCA 1 DWD-FD'S(230V)
3612802420 240V 2KW.1R0A721003.RW8TF.IRCA 1 1 DWD-FD'S(240V)
3612802430 110V 1KW.1R0A721004.RW8TF.IRCA 1 DWD-F'S(110V)
3612802440
120V 1KW.1R0A721005.RW8TF1PE.IRCA
1
DWD-FD'S(120-127V)
3612803700
230V 2000W.1R5A721002.IRCA FUSE 2EA
1
DWD-F'S(230V), VDE
D33 UNIT BUBBLE PUMP AS 36189L4120 220-240V DBK-240DB RP CHSHION 1 OPTION(220-240)
36189L4G10 100-130 DBK-115DB RP-CUSH OPTION(100-130)
D34 SPRING SUSPENSION 3615115310 D3.2, L164 2
D35 THERMISTOR WASH 361AAAAB10 R25=1.704kΩ R80=11.981kΩ 1
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
