4. DIRECTION FOR DISASSEMBLY
11
DIRECTION FOR DISASSEMBLY
DOOR LOCK SWITCH
1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet.
HEATER AND THERMISTOR
1) Remove four screws on the back cover, and
remove the back cover.
2) Remove connectors and the earth terminal.
3) Remove two screws, and remove the door lock
switch.
To Next Page
