19
EXPLODE VIEW AND PARTS LIST
T01
BALANCER WEIGHT F AS
3616111800 D-FT1081's, 8kg 1
T02 SPECIAL SCREW 3616029400 SWCH 8.5X30 6
T03 GASKET 3612327300 EPDM, D-FT1081 1
T04 CLAMP GASKET AS 3611204520 HSW3, GS 1
T05 TUB *F 3618831000 FRPP, FT1081 1
T06 SPECIAL SCREW 3616062700 SWRCH 18A 5.6X30 12
T07 DAMPER FRICTION 361A700140 70N CIMA ST=170-260 DL=202 1
T08 DAMPER FRICTION 361A700140 70N CIMA ST=170-260 DL=202 1
T09 DAMPER PIN 361A700200 AKS D=14.5 2
T10
SPRING SUSPENSION *L
3615118700
FU1081,D=3.2 L=173,K=0.664 YELLOW COATING
1
T11
SPRING SUSPENSION *R
3615118750
FU1081,D=3.2 L=167,K=0.455 SILVER COATING
1
T12 HOSE VENT 3613267100 EPDM 1
T13 CLAMP HOSE 3611204700 D26 1
T14 HOSE DRAIN 3613267300 EPDM 1
T15 AIR TRAP 361A500101 PP 1
T16 HOSE AIR 3613268600 ID=4,OD=8, L=580 1
T17 CLAMP AS 3611203210 ID=61, WIRE+GUIDE+BOLT, GS 1
T18 CLAMP HOSE 3611201401 HSW3,YW,D2.6,ID36,W44.5 1
T19 CLAMP HOSE 3611204700 D26 1
T20 DRUM SUB AS 3617004002 D-F 0.4T(CENTER, REAR), 0.5(FRONT) 1
T21 LIFTER WASH 361A400410 PP D-F'S NANO 3
T22 SPIDER AS 361A301500 D-FT1081 1
T23 SPECIAL SCREW 3616029500 SUS430 8*25 3
T24 WATER SEAL 361A600100 NBR 1
T25 BEARING INNER 3616303100 F,L,E,U,6206Z 1
T26 BEARING HOUSING 3616305600 ALDC, FT1081 1
T27 BEARING OUTER 3616303200 F,L,E,U,6205Z 1
T28 TUB REAR 3618831100 FRPP, FT1081 1
T29 SEALING TUB 3612321601 EPDM L1600(-0~ +10) 1
T30 FIXTURE HEATER 3612007300 SUS 0.7T 440X45 1
T31 SCREW TAPPING 7122401408 T2S TRS 4*14 SUS,STS 2
T32 HEATER WASH 3612803600 230V 2000W.1R5A721001.IRCA FUSE 2EA 1
3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
3612803800 240V 2000W.1R5A721003.IRCA FUSE 2EA 1
3612802400 220V 2KW.1R0A721001.RW8TF.IRCA 1
3612802420 240V 2KW.1R0A721003.RW8TF.IRCA 1
T33 THERMISTOR WASH 361AAAAB10 R25=1.704_ R80=11.981_ 1
T34
UNIT MOTOR UNIVERSAL
36189L4H30
DC220V 50HZ 2P PI340 45T DUM-66 TONLON
1
36189L4H10
AC220~240/50 G&J GJ-2UA005A 2P PI340 45T(CCA)
1 option
36189L4H20 DC220/50 C&M 2P PI340 45T(AL) 1 option
T35 SPECIAL SCREW 3616007400 T2S TRS 4X10+24 2
T36 UNIT BUBBLE PUMP AS 36189L4120 220-240V DBK-240DB RP CHSHION 1
T37 PULLEY 3618433200 ALDC, D-FU
T38 BELT V 3616591110 GATES 4PJ1120 BUTADIENE RUBBER 1
T39 SPECIAL BOLT AS 3616029600 SWCH 10*30,F/L BOLT S.P/W SEAL LOCK 1
T40
BALANCER WEIGHT *T AS
3616110700 PP, D-LU1011, 2.48KG 1
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
1 piece
SVC part
CE, CB
Standard
To Next Page
