EXPLODE VIEW AND PARTS LIST
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
D01 TUB REAR AS 3618829900
TUB REAR(FRPP) + BEARING HOUSING(ALDC)
1
D02 BEARING INNER 3616304700 6205ZZ SHENS 1
D03 BEARING OUTER 3616304800 6204ZZ SHENS 1
D04 WATER SEAL 361A600300 NBR 1
D05 GASKET TUB 3612324100 PI=4.5, L=1650, EPDM 1
D06 FIXTURE HEATER 3612009400 SUS, PI=2 1
D07 TUB FRONT 3618829600 FRPP 1
D08 GASKET 3612323500 EPDM 1
D09 CLAMP GASKET AS 3611204520 HSW3 1
D10 DRUM SUB AS 3617010400 SUS T=0.4 1
D11 SPIDER AS 361A301000 SPIDER(ALDC-8) + SHAFT(SM45C) 1
D12 SPECIAL BOLT 3616063000 STS430 M6*21 SI-LOCK 3
D13 LIFTER WASH 361A401110 NANO 3
D14 SPECIAL SCREW(TUB) 3616062700 SWRCH18A 5.6*30 12
D15 PULLEY 3618433210 PA6+GF30%, SERRATION 1
D16 SPECIAL BOLT AS(PULLEY) 3616063100 SWRCH10A M8*22 PW SI-LOCK 1
D17 UNIT MOTOR UNIVERSAL 36189L5H00 SOYEA 2POLES 38T 1
D18 SPECIAL SCREW(MOTOR) 3616062800 SWRCH18A 7.4*25.5 2
D19 BELT V 3616591300 GATES 3PJ1134 BUTADIENE RUBBER 1
3612802450 220V 1.8KW IRCA
D20 HEATER WASH 3612802460 230V 1.8KW IRCA 1
3612802470 240V 1.8KW IRCA
D21 THERMISTOR WASH 361AAAAB10 R25=1.704KΩ, R80=11.981KΩ 1
D22 HARNESS EARTH 3612794450 L=180 1
D23 BALANCER WEIGHT 3616108900 PP, INSERT 4KG 2
D24 SPECIAL SCREW(BALANCER) 3616062900 SWRCH18A 8*31 PW 6
D25 HOSE INLET 3613271600 EPDM 1
D26 CLAMP HOSE I 3611201400 HSW3, D=2.6, MFZN D=38 1
D27 SPRING SUSPENSION 3615115900 K=0.39, L=137 2
D28 FRAME TOP 3612208500 SGCC T=1.2
HOSE DRAIN(EPDM) + AIR TRAP(PP)
D29 HOSE DRAIN AS 3613272300
+ HOSE AIR(ID=4.0, OD=8, L=560, EPDM)
1
+ CLAMP AS(ID=81, CIMA)
+ CLAMP HOSE(D=26) + CLAMP HOSE I(D=38)
D30 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 1
D31 DAMPER FRICTION
361A700110 70N AKS
2
361A700140 70N CIMA
D32 DAMPER PIN 361A700200 AKS D=14.5 2
D33 UNIT BUBBLE PUMP AS 36189L4140 220-240V RP CHUSHION=760 1
D34 SPECIAL SCREW(BUBBLE) 3616007400 T2S TRS 4X10+24 2
D35 EMI FILTER(K27) 3611908740 0.22UF 1
D36 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 1
