EXPLODE VIEW AND PARTS LIST
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
E01 CABINET
3610812700 SGCC(GI) T=0.7 PCM
1
3610812710 SGCC(GI) T=0.7 PAINTING
E02 FRAME LOWER 3612208400 SGCC T=0.8 1
E03
BASE U L 3610393100 SGCC T=1.4 1
BASE U R 3610393110 SGCC T=1.4 1
3617703800
FOOT(BUTYL)+SPECIAL NUT(SCP1)
4
E04 LEG ADJUST AS +SPECIAL BOLT(10x1.25, 51MM)
3617703811 CHINA, FOOT+SPECIAL NUT(M10x1, 25P)
3612797500 COLD+HOT, BB
3612797510 COLD+HOT, NON-BB
E05 HARNESS AS
3612797520 COLD, NON-BB, NON-REACTOR
1
3612797530 COLD, BB, NON-REACTOR
3612797540 COLD, NON-BB, REACTOR
3612797550 COLD, BB, REACTOR
E06 UNIT DRAIN PUMP AS 36189L5K10 220-240V, 50Hz, 30W, AL, NO-HOLE 1
E07 SCREW TAPPING 7112401211 T1 TRS 4*12 MFZN 1
E08 HOSE DRAIN O AS 3613268520 L=1800, STRAIGHT TYPE, CLAMP PI=27 1
E09 CLAMP HOSE 3611206400 NYLON, DA-18N 1
E10 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 1
E11 PLATE T AS 3614540300 HIPS+MFC(400x577x9.3T)+STAPLE(8x10) 1
E12 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 2
E13 REACTOR AS 3615800100
REACTOR(RT-046B)+BRACKET REACTOR(PP)
1
+SCREW TAPPING(T2S TRS 4x14 MFZN)
E14 SCREW TAPPING 7122401411 T2S TRS 4x14 MFZN 2
E15 CORD POWER AS 3611339630 EU-2PIN H05VV-F 1.0SQ 250V 16A 1.4M 1
E16 SENSOR PRESSURE 3614825310 5V DL-DW12 INLET 180° 1
E17 SCREW TAPPING 7122401411 T2S TRS 4x14 MFZN 1
