Daewoo DWD-M8021 - Installation Instructions; Removing transit bolts; Location of washer; Inlet hose connection

3
SPECIFICATIONS
■
Accessories
■
DWD-M802X SERIES
POWER SOURCE 220~240V / 50, 60Hz
DIMENSION (WXDXH) 595mm x 440mm x 850mm
WEIGHT 43 Kg
WATER CONSUMPTION 42 l
POWER CONSUMPTION 2000 W
MAXIMUM MASS WASH 5.5 / 6 Kg
OF TEXTILE SPIN 5.5 / 6 Kg
WASHER TYPE DRUM TYPE (FRONT LOADING WASHING MACHINE)
OPERATING WATER PRESSURE 0.3~8kgf/cm
2
(29.4~784KPa)
DWD-M8021/8022/8023
MODEL
ADJUSTABLE LEG
CONTROL PANEL
DOOR
DETERGENT CASE
INLET HOSE (HOT)
(OPTION)
INLET HOSE (COLD)
COVER PUMP
POWER CORD
HOSE DRAIN
Inlet hose
(Cold: 1EA, Hot: 1EA)
Manual Sticker holder (3EA)
Guide Hose Drain
(Option)
